Philips DCM230 - Electrical Parts List

ELECTRICAL PARTSLIST - MAIN BOARD (only for -/55
)
- IC & TRANSISTORS
-
D1 996500042437 CH-DIODE SS14 SMA/DO-214AC
IC13 996510008325 IC (LIBERAL) SC1308-01
IC6 996510002113 IC AP1501 (TO263-5L)
U8 996510002114 IC BR24C02F-WE2
IC3 994000004532 IC KA7808E (TO-220)
IC702 994000004622 IC LA6548NH HSOP28H
IC701 996500039807 IC LC78690NW-UPHI-E (SQFP80)
U2 994000002839 IC LM1117S-3.3 SOT-223
U9 994000002839 IC LM1117S-3.3 SOT-223
IC9 996510002117 IC OTI6889 (LQFP-80)
IC10 994000004607 IC PT2314
IC4 996500039808 IC SM LM324D (933984860668)
IC8 996510002118 IC SST39VF010-70-4C-WHE (1M)
IC104 996510002119 IC TA7291S
IC11 994000001203 IC TDA8947J/N3 (935274472112)
IC14 996500039809 IC YD4558 (SOP-8)
IC15 996500039809 IC YD4558 (SOP-8)
U1 996510008324 MCU GY383 (OTP)
Q10 996510000849 NPN TRANSISTORS 9014C
Q15 996510000849 NPN TRANSISTORS 9014C
Q2 996510008321 SMD TRANSISTORS AO3401 SOT23
Q23 996510008321 SMD TRANSISTORS AO3401 SOT23
Q25 996510008321 SMD TRANSISTORS AO3401 SOT23
Q1 994000004338 SMD TRANSISTORS PMBT3904 SOT23
Q17 994000004338 SMD TRANSISTORS PMBT3904 SOT23
Q18 994000004338 SMD TRANSISTORS PMBT3904 SOT23
Q24 994000004338 SMD TRANSISTORS PMBT3904 SOT23
Q26 99400000433
8
SMD TRANSISTORS PMBT3904 SOT23
Q4 994000004338 SMD TRANSISTORS PMBT3904 SOT23
Q6 994000004338 SMD TRANSISTORS PMBT3904 SOT23
Q12 994000004337 TRANSISTORS 2SD1936T-AC
Q13 99400000433
7
TRANSISTORS 2SD1936T-AC
Q19 994000004337 TRANSISTORS 2SD1936T-AC
Q20 994000004337 TRANSISTORS 2SD1936T-AC
Q501 994000004337 TRANSISTORS 2SD1936T-AC
Q502 994000004337 TRANSISTORS 2SD1936T-AC
Q14 996500039345 TRANSISTORS 2W 8050D
Q21 996500039345 TRANSISTORS 2W 8050D
Q22 996500039345 TRANSISTORS 2W 8050D
Q8 996500039345 TRANSISTORS 2W 8050D
Q16 996500039346 TRANSISTORS 2W 8550D
Q3 996510000992 TRANSISTORS SPD18P06P
