FUNCTIONAL OVERVIEW 11
Rear panel
Caution: Do not touch the inner pins of the jacks on the rear
panel connectors. Electrostatic discharge may cause permanent
damage to the unit.
L
R
CVBS
VIDEO OUT
COAXIAL
AUDIO
Y
S-VIDEO
OPTICAL
1
DIGITAL AUDIO OUT
PCM/MPEG2/AC3/DTS
1
22
C
B
C
R
MAINS
Video Out (CVBS)
- connect to a TV with CVBS video inputs
Video Out (Y CR CB)
- connect to your TV Y,CR,CB inputs for better picture
quality
Video Out (S-Video)
- connect to a TV with S- Video (Y/C) inputs
Digital audio out jack (optical)
- connect to digital (optical) equipment
Digital audio out jack (coaxial)
- connect to digital (coaxial) equipment
Audio / L/R (Left/Right)
- connect to an amplifier, receiver or stereo system
MAINS (AC) power jack
- connect to the power source
