10. Spare Part list DVD627K/781/782

2717 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2720 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2721 4822 051 30109 RST SM 0603 RC21 10R PM5 R

2722 4822 126 13883 CER1 0603 NP0 50V 220P PM5 R

2723 3198 016 31010 CER1 0603 NP0 50V 100P PM5 R

2724 4822 051 30109 RST SM 0603 RC21 10R PM5 R

2725 4822 126 13883 CER1 0603 NP0 50V 220P PM5 R

2726 3198 016 31010 CER1 0603 NP0 50V 100P PM5 R

2727 3198 017 44740 CER2 0603 Y5V 10V 470N P8020 R

2728 4822 051 30109 RST SM 0603 RC21 10R PM5 R

2729 5322 126 11583 CER2 0603 Y5V 50V 10N P8020 R

2730 4822 126 13883 CER1 0603 NP0 50V 220P PM5 R

2731 3198 016 31010 CER1 0603 NP0 50V 100P PM5 R

2734 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2735 3198 029 24790 ELCAP 7MM 16V S 47U PM20 A

2737 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2738 3198 017 41050 CER2 0603 Y5V 10V 1U P8020 R

2739 3198 017 41050 CER2 0603 Y5V 10V 1U P8020 R

2740 3198 017 41050 CER2 0603 Y5V 10V 1U P8020 R

2741 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2742 3198 029 24790 ELCAP 7MM 16V S 47U PM20 A

2744 4822 126 13883 CER1 0603 NP0 50V 220P PM5 R

2747 4822 126 13883 CER1 0603 NP0 50V 220P PM5 R

2748 3198 016 31010 CER1 0603 NP0 50V 100P PM5 R

2749 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2751 4822 126 14241 CER2 0603 X7R 50V 330P PM10 C

2752 4822 126 13883 CER1 0603 NP0 50V 220P PM5 R

2753 3198 016 31010 CER1 0603 NP0 50V 100P PM5 R

2758 4822 126 13909 CER2 0603 X7R 50V 680P PM10 C

2760 3198 017 33320 CER2 0603 X7R 50V 3N3 PM10 R

2763 4822 126 13909 CER2 0603 X7R 50V 680P PM10 C

2764 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2765 4822 126 13909 CER2 0603 X7R 50V 680P PM10 C

2767 3198 017 33320 CER2 0603 X7R 50V 3N3 PM10 R

2770 4822 126 13909 CER2 0603 X7R 50V 680P PM10 C

2771 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2772 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2773 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2774 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2775 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2776 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2778 4822 124 40207 ELCAP YK 25V 100U PM20 A

2779 4822 124 40196 ELCAP NS 16V 220U PM20 T

2781 4822 124 40196 ELCAP NS 16V 220U PM20 T

2782 4822 124 40248 ELCAP NS 25V 10U PM20 T

2783 4822 124 40196 ELCAP NS 16V 220U PM20 T

2784 4822 124 40196 ELCAP NS 16V 220U PM20 T

2785 4822 124 40196 ELCAP NS 16V 220U PM20 T

2786 4822 124 40196 ELCAP NS 16V 220U PM20 T

2788 3198 029 24790 ELCAP 7MM 16V S 47U PM20 A

2789 3198 029 24790 ELCAP 7MM 16V S 47U PM20 A

2790 4822 124 40207 ELCAP YK 25V 100U PM20 A

2791 3198 029 24790 ELCAP 7MM 16V S 47U PM20 A

2793 4822 124 40196 ELCAP NS 16V 220U PM20 T

2795 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2796 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2797 4822 124 40207 ELCAP YK 25V 100U PM20 A

2798 4822 124 40207 ELCAP YK 25V 100U PM20 A

2799 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2800 4822 124 40207 ELCAP YK 25V 100U PM20 A

2802 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2803 5322 122 33861 CER1 0603 NP0 50V 120P PM5 R

2805 4822 124 81151 ELCAP RE2 50V S 22U PM20 COL A

2806 4822 124 81151 ELCAP RE2 50V S 22U PM20 COL A

2807 4822 124 40207 ELCAP YK 25V 100U PM20 A

2809 4822 122 33741 CER1 0603 NP0 50V 10P PM0P5 R

2810 3198 017 41050 CER2 0603 Y5V 10V 1U P8020 R

2811 3198 023 41040 CER2 0603 Y5V 25V 100N COL

2812 4822 124 81151 ELCAP RE2 50V S 22U PM20 COL A

2813 5322 122 33861 CER1 0603 NP0 50V 120P PM5 R

Resistors

3602 4822 051 30332 RST SM 0603 3K3 PM5 COL

3603 4822 051 30102 RST SM 0603 1K PM5 COL

3604 4822 117 13632 RST SM 0603 100K PM5 COL

3605 4822 051 30223 RST SM 0603 22K PM5 COL

3607 4822 117 12891 RST SM 0603 220K PM5 COL

3608 4822 051 30102 RST SM 0603 1K PM5 COL

3609 4822 051 30008 RST SM 0603 JUMP. MAX 0R05 C

3611 4822 051 30103 RST SM 0603 RC21 10K PM5 R

3612 4822 051 30008 RST SM 0603 JUMP. MAX 0R05 C

3614 4822 051 30008 RST SM 0603 JUMP. MAX 0R05 C

3616 4822 051 30103 RST SM 0603 RC21 10K PM5 R

3617 4822 051 30103 RST SM 0603 RC21 10K PM5 R

3618 4822 051 30008 RST SM 0603 JUMP. MAX 0R05 C

3620 4822 051 30103 RST SM 0603 RC21 10K PM5 R

3621 4822 051 30103 RST SM 0603 RC21 10K PM5 R

3622 4822 051 30008 RST SM 0603 JUMP. MAX 0R05 C

3623 4822 051 30008 RST SM 0603 JUMP. MAX 0R05 C

3625 4822 051 30273 RST SM 0603 RC21 27K PM5 R

3626 4822 117 13632 RST SM 0603 100K PM5 COL

3629 4822 117 12139 RST SM 0603 RC21 22R PM5 R

3630 4822 117 12139 RST SM 0603 RC21 22R PM5 R

3631 4822 051 20108 RST SM 0805 1R PM5 COL R

3632 4822 051 20108 RST SM 0805 1R PM5 COL R

3633 4822 051 20108 RST SM 0805 1R PM5 COL R

3634 4822 051 20108 RST SM 0805 1R PM5 COL R

3635 4822 051 30103 RST SM 0603 RC21 10K PM5 R

3636 4822 051 30203 RST SM 0603 RC0603 20K PM5 R

3637 4822 051 30333 RST SM 0603 RC21 33K PM5 R

3638 4822 051 30203 RST SM 0603 RC0603 20K PM5 R

3639 4822 051 30203 RST SM 0603 RC0603 20K PM5 R

3640 2322 704 67504 RST SM 0603 RC22H 750K PM1 R

3642 2322 704 67504 RST SM 0603 RC22H 750K PM1 R

3643 4822 051 30334 RST SM 0603 RC21 330K PM5 R

3644 4822 051 30334 RST SM 0603 RC21 330K PM5 R

3645 4822 117 12917 RST SM 0603 RC21 1R PM5 R

3646 4822 051 30472 RST SM 0603 4K7 PM5 COL

3647 4822 051 30472 RST SM 0603 4K7 PM5 COL

3648 4822 117 13632 RST SM 0603 100K PM5 COL

3650 4822 051 30008 RST SM 0603 JUMP. MAX 0R05 C

3651 4822 117 13632 RST SM 0603 100K PM5 COL

3652 4822 051 30339 RST SM 0603 RC21 33R PM5 R

3655 4822 051 30183 RST SM 0603 RC21 18K PM5 R

3658 4822 117 13608 RST SM 0603 RC21 4R7 PM5 R

3659 4822 117 12902 RST SM 0603 RC21 8K2 PM5 R

3660 5322 117 13062 RST SM 0603 RC22H 390R PM1 R

3661 2322 704 67504 RST SM 0603 RC22H 750K PM1 R

3662 4822 051 30203 RST SM 0603 RC0603 20K PM5 R

3663 4822 051 30183 RST SM 0603 RC21 18K PM5 R

3664 4822 051 30008 RST SM 0603 JUMP. MAX 0R05 C

3665 4822 051 30103 RST SM 0603 RC21 10K PM5 R

3666 4822 051 30102 RST SM 0603 1K PM5 COL

3667 4822 051 30153 RST SM 0603 MCR03 15K PM5 R

3668 4822 051 30109 RST SM 0603 RC21 10R PM5 R

3669 4822 117 13608 RST SM 0603 RC21 4R7 PM5 R

3670 4822 051 30109 RST SM 0603 RC21 10R PM5 R

3671 4822 117 13608 RST SM 0603 RC21 4R7 PM5 R

3672 4822 051 30339 RST SM 0603 RC21 33R PM5 R

3673 4822 051 30339 RST SM 0603 RC21 33R PM5 R

3674 4822 051 30339 RST SM 0603 RC21 33R PM5 R

3675 4822 051 30339 RST SM 0603 RC21 33R PM5 R

3676 4822 117 13576 RST NETW 1206 4X 33R PM5 COL R

3680 4822 051 30103 RST SM 0603 RC21 10K PM5 R

3683 5322 117 13055 RST SM 0603 RC22H 75R PM1 R

3686 5322 117 13055 RST SM 0603 RC22H 75R PM1 R
