Philips DVDR3305/02 - Video Performance

EN 3
3139 785 3093x
1.
Technical Specifi cations and Connection Facilities
1.3.6 Tuning
Automatic Search Tuning
Scanning time without antenna : typ. 3 min.
Stop level (vision carrier) :  37dBV
Maximum tuning error of a recalled
program : ± 62.5 kHz
Maximum tuning error during
operation : ± 100 kHz
Tuning Principle
Automatic B, G, I, DK and L/L’ detection
Manual selection in “STORE” mode
1.4 Analogue Inputs / Outputs
1.4.1 SCART 1 (Connected to TV)
Pin Signals:
1 - Audio R 1.8V RMS
2 - Audio R
3 - Audio L 1.8V RMS
4 - Audio GND
5 - Blue / GND
6 - Audio L
7 - Blue out
8 - Function switch < 2V = TV
> 4.5V / < 7V = asp. Ratio 16:9 DVD
> 9.5V / < 12V = asp. Ratio 4:3 DVD
9 - Green GND
10 - NC
11 - Green 0.7Vpp ± 0.1V into 75 (*)
12 - NC
13 - Red GND
14 - Fast switch GND
15 - Red out 0.7Vpp ± 0.1V into 75 (*)
16 - Fast switch
RGB / CVBS < 0.4V into 75 = CVBS
>1V / < 3V into 75 = RGB
17 - CVBS GND OUT
18 - CVBS GND IN
19 - CVBS out 1Vpp ± 0.1V into 75 (*)
20 - CVBS in
21 - Shield
1.4.2 SCART 2 (Connected to AUX)
Pin Signals:
1 - Audio R 1.8V RMS
2 - Audio R
3 - Audio L 1.8V RMS
4 - Audio GND
5 - Blue GND
6 - Audio L
7 - Blue in
8 - Function switch
9 - Green GND
10 - NC
11 - Green in
12 - NC
13 - Red GND
14 - Fast switch GND
15 - Red in
16 - Fast switch
RGB / CVBS
17 - CVBS GND OUT
18 - CVBS GND IN
19 - CVBS / RGB
out sync 1Vpp ± 0.1V into 75 (*)
20 - CVBS in
21 - Shield
(*) for 100% white
1.4.3 Audio/Video Front Input Connectors
Audio - Cinch
Input voltage : 2.2Vrms
Input impedance : > 10k
Video - Cinch
Input voltage : 1Vpp ± 3dB
Input impedance : 75
Video - YC (Hosiden)
According to IEC 933-5
Superimposed DC-level on pin 4 (load > 100k)
< 2.4V is detected as 4:3 aspect ratio
> 3.5V is detected as 16:9 aspect ratio
Input voltage Y : 1Vpp ± 3dB
Input impedance Y : 75
Input voltage C : burst 300mVpp ± 3dB
Input impedance C : 75
1.4.4 Audio/Video Output rear Connectors
Audio - Cinch
Output voltage : 2Vrms max.
Output impedance : > 10k
Video - Cinch
Output voltage : 1Vpp ± 3dB
Output impedance : 75
Video - YC (Hosiden)
According to IEC 933-5
Superimposed DC-level on pin 4 (load > 100k)
< 2.4V is detected as 4:3 aspect ratio
> 3.5V is detected as 16:9 aspect ratio
Output voltage Y : 1Vpp ± 10/-15%
Output voltage C : 300mVpp ± 1/-4dB
1.5 Video Performance
All outputs loaded with 75 
SNR measurements over full bandwidth without weighting.
1.5.1 SCART (RGB)
SNR : > -65dB on all output
Bandwidth : 4.8MHz ± 2dB
1.6 Audio Performance CD
1.6.1 Cinch Output Rear
Output voltage 2 channel mode : 2Vrms ± 2dB
Channel unbalance (1kHz) : < 1dB
Crosstalk 1kHz : > 95dB
Crosstalk 16Hz-20kHz : > 87dB
Frequency response 20Hz-20kHz : ± 0.2dB max
Signal to noise ratio : > 85dB
Dynamic range 1kHz : > 83dB
Distortion and noise 1kHz : > 83dB
Distortion and noise 16Hz-20kHz : > 75dB
Intermodulation distortion : > 70dB
Mute : > 95dB
Outband attenuation: : > 40dB above 30kHz
