M echanical and Dism antling Instructions
Step6: Dism antling M ain B oard, first disconnect the
connector, and then rem ove the relative screw s, (Figure 7)
Step7: Rem ove the 3 screw s on pow er board to dism antle
the pow er board. (Figure8)
Figure 8
CON 6
2-3
Figure 7
