Philips DVP520/05 - Page 45

C95 28-AB0103-ZFX CAP.SMD 10NF 50V +80-20% 0603
L15 33-KLL189-KTX SMD. COIL 1.8 UH +/-10% 0603
C96 28-AB0101-JCX SMD. CAP 100 pF 50VDC +/-5% L16 33-KLL189-KTX SMD. COIL 1.8 UH +/-10% 0603
C97 28-AB0104-ZFX
SMD. CAP 0.1 UF 50V +80%-20% 0603
L17 33-KLL189-KTX SMD. COIL 1.8 UH +/-10% 0603
C98 28-AB0153-ZFX SMD. CAP 0.015 UF 50V 0603 F L18 33-KLL189-KTX SMD. COIL 1.8 UH +/-10% 0603
C99 28-AB0331-JCX SMD. CAP 330 pF 50V +/-5% 0603 L19 33-KLL189-KTX SMD. COIL 1.8 UH +/-10% 0603
L2 35-339740-008 FERR BEAD BF40TA-3.5X6X1
CONNECTOR
L20 33-KLL189-KTX SMD. COIL 1.8 UH +/-10% 0603
CN1 46-33079W-10X PIN BASE *10 TJC3-10A L3 33-ELN501-NTX CHIP BEAD 500 OHM +/-25%
CN10 47-389910-03X AV SOCKET L4 33-ELN501-NTX CHIP BEAD 500 OHM +/-25%
CN2 46-37146W-24X PIN BASE FPC 0.5-SMT-24PW L5 35-339740-008 FERR BEAD BF40TA-3.5X6X1
CN3 46-35199W-05X CONN.PH-5A 5PIN PITCH=2.0MM L6 33-ELN501-NTX CHIP BEAD 500 OHM +/-25%
CN4 46-35199W-06X CONN.PH-6A 6PIN PITCH-2.0MM L7 34-A100K0-1IX COIL CHOKE 10 UH +/-10%
CN5 46-35199W-10X
CONN. PH-10 10PIN PITCH=2.0mm
L8 34-A100K0-1IX COIL CHOKE 10 UH +/-10%
CN7 47-RCA131-XX0 JACK RCA RCA-353D4A01-170 L9 33-ELN501-NTX CHIP BEAD 500 OHM +/-25%
CN9 47-SCA008-XX0 SCART SOCKET
TRANSISTORS
DIODE
Q1 11-0S8050-CBX TRANSISTOR S8050C
D1 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q10 12-G9014M-CBX TRANSISTOR SMT 3DG9014M
D10 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q11 12-G9012M-HBX TRANSISTOR SMT 3CG9012M
D11 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q12 12-G9012M-HBX TRANSISTOR SMT 3CG9012M
D12 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q13 12-G9012M-HBX TRANSISTOR SMT 3CG9012M
D13 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q14 12-G9014M-CBX TRANSISTOR SMT 3DG9014M
D14 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q15 12-G9014M-CBX TRANSISTOR SMT 3DG9014M
D15 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q16 12-G9014M-CBX TRANSISTOR SMT 3DG9014M
D16 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q17 12-G9012M-HBX TRANSISTOR SMT 3CG9012M
D18 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q18 12-G9014M-CBX TRANSISTOR SMT 3DG9014M
D19 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q19 12-G9014M-CBX TRANSISTOR SMT 3DG9014M
D2 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q2 12-G9014M-CBX TRANSISTOR SMT 3DG9014M
D3 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q20 12-G9014M-CBX TRANSISTOR SMT 3DG9014M
D4 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q3 12-SK3018-0BX TRANSISTOR 2SK3018T106
D6 19-AA0820-FTX SMD RES 82 OHM 1/16W +/-1% Q4 12-SK3018-0BX TRANSISTOR 2SK3018T106
D7 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q5 11-TC8550-CBX TRANSISTOR KTC8550-C
D8 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q6 11-TC8550-CBX TRANSISTOR KTC8550-C
D9 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 Q7 12-G9012M-HBX TRANSISTOR SMT 3CG9012M
Q8 12-G9012M-HBX TRANSISTOR SMT 3CG9012M
INDUCTANCE
Q9 12-G9014M-CBX TRANSISTOR SMT 3DG9014M
L1 33-ELN501-NTX CHIP BEAD 500 OHM +/-25%
L11 33-ELN501-NTX CHIP BEAD 500 OHM +/-25%
L12 33-ELN501-NTX CHIP BEAD 500 OHM +/-25%
L13 33-ELN501-NTX CHIP BEAD 500 OHM +/-25%
8-13
