Electrical Parts List-Front Board
CAPACITORS SWITCH CRYSTAL CONNECTOR & IC
C300 28-AB0101-JCX SMD. CAP 100 pF 50VDC +/-5% CN301 46-FH025T-04K HS 4P PH-4Y/JC20-4Y L=250
C301 28-AB0101-JCX SMD. CAP 100 pF 50VDC +/-5% CN303 46-FH015T-10K HS 10P PH-10Y/JC20-10Y L=150
C302 28-AB0101-JCX SMD. CAP 100 pF 50VDC +/-5% K302 48-TAC020-XX0 SWITCH TACT TSAB-1
C303 28-AB0104-ZFX SMD. CAP 0.1 UF 50V +80%-20% 0603 K303 48-TAC020-XX0 SWITCH TACT TSAB-1
C304 25-HCB470-M1X CAP. ELEC 47 UF 16V +/-20%(SM) K304 48-TAC020-XX0 SWITCH TACT TSAB-1
C305 28-AB0104-ZFX SMD. CAP 0.1 UF 50V +80%-20% 0603 U301 13-0SS312-00B VFD DRIVER IC S0792GB
C306 28-AB0104-ZFX SMD. CAP 0.1 UF 50V +80%-20% 0603 VFD 14-VFD520-DX0 VFD VFD20-0707FN
C307 25-HCB470-M1X CAP. ELEC 47 UF 16V +/-20%(SM)
C308 28-AB0104-ZFX SMD. CAP 0.1 UF 50V +80%-20% 0603
DIODE
C314 25-HFB220-M1X CAP. ELEC 22 UF 50V +/-20% D301 10-1N4148-ABX DIODE 1N4148 (SWITCHING)
C315 28-AB0104-ZFX SMD. CAP 0.1 UF 50V +80%-20% 0603 D302 14-LED03R-XX0 LED RED HFR303J(R)(3mm)
RESISTORS
R300 19-AA0101-JTX RES. SMD 100 OHM 1/16W +/-5%
ELECTRICAL PARTS LIST-SWITCH BOARD
R301 19-AA0101-JTX RES. SMD 100 OHM 1/16W +/-5%
R302 19-AA0101-JTX RES. SMD 100 OHM 1/16W +/-5% CN302 46-35135W-04X PIN BASE PH-04AW
R303 19-AA0103-JTX RES. SMD 10K OHM 1/16W +/-5% K301 48-TAC020-XX0 SWITCH TACT TSAB-1
R304 19-AA0103-JTX RES. SMD 10K OHM 1/16W +/-5%
R305 19-AA0103-JTX RES. SMD 10K OHM 1/16W +/-5%
R306 19-AA0513-JTX RES.SMD 51K 1/16W +/-5% 0603
R307 19-AA0103-JTX RES. SMD 10K OHM 1/16W +/-5%
R308 19-AA0103-JTX RES. SMD 10K OHM 1/16W +/-5%
R309 19-AA0103-JTX RES. SMD 10K OHM 1/16W +/-5%
R310 19-AA0103-JTX RES. SMD 10K OHM 1/16W +/-5%
R312 19-AA0471-JTX RES. SMD 470 OHM 1/16W +/-5%
R313 19-AA0000-JTX RES. SMD 0 OHM 1/16W +/-5%
R317 19-AA0101-JTX RES. SMD 100 OHM 1/16W +/-5%
R327 19-AA0330-JTX RES. SMD 33 OHM 1/16W +/-5%
REM301 02-IRR005-XX4
IR RECEIVER MODULE AT138BV3T-12P
Note: Only the parts mentioned in this list are normal service
spare parts.
6-5
