Mechanical and Dismantling Instructions
Step5
: Dismantling Main Board, first disconnect the
connector, and then remove the relative screws, (Figure 7)
Step6
: Remove the 3 screws on power board to dismantle
the power board. (Figure 8)
Figure 6
Figure 8
CON 6
2-3
Figure 7
