Electrical Parts List-Power Board
CAPACITORS DIODE
C201 27-MDK104-MVX CAP. M.P.E 0.1UF 250VAC +/-20% D201 10-1N4007-EBX DIODE IN4007
C203 25-BMF470-M1X CAP. ELEC 47UF 400V +/-20% D202 10-1N4007-EBX DIODE IN4007
C204 26-APK102-MEX CAP. CER 1000PF 400VAC +/-20%E D203 10-1N4007-EBX DIODE IN4007
C205 26-APK222-MEX CAP. CER 2200PF 400VAC+/-20% E D204 10-1N4007-EBX DIODE IN4007
C206 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% D205 10-0001H8-FBX DIODE 1H8 (FAST RECOVERY)
C207 28-BB0471-JCX SMD. CAP 470pF 50V +/-5% D206 10-0FR104-FBX DIODE FR104 (FAST RECTIFIER)
C208 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% D207 10-0FR102-FBX DIODE FR102 (1A/100V)
C209 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% D208 10-0FR102-FBX DIODE FR102 (1A/100V)
C210 25-BFB100-M1X CAP. ELEC 10 UF 50V +/-20% D209 10-0FR102-FBX DIODE FR102 (1A/100V)
C211 25-BDB101-M1X CAP. ELEC 100 UF 25V +/-20% D210 10-0FR102-FBX DIODE FR102 (1A/100V)
C212 25-BFB100-M1X CAP. ELEC 10 UF 50V +/-20% D211 10-0FR102-FBX DIODE FR102 (1A/100V)
C213 25-BDB101-M1X CAP. ELEC 100 UF 25V +/-20% D212 10-0RU3YX-F0X
DIODE RU3YX (FAST RECTIFIER)
C214 25-BDB101-M1X CAP. ELEC 100 UF 25V +/-20% D213 10-0RU3YX-F0X
DIODE RU3YX (FAST RECTIFIER)
C215 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% D214 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM
C216 25-BDB101-M1X CAP. ELEC 100 UF 25V +/-20% D215 10-1N4148-ABX DIODE 1N4148 (SWITCHING)
C217 25-BDB101-M1X CAP. ELEC 100 UF 25V +/-20% ZD203 10-P6KE20-0AX DIODE P6KE200A
C218 28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805 ZD204 10-79C12V-DBX DIODE ZENER 12V 1/2W 5%
C219 25-BHB109-M1X CAP. ELEC 1 UF 100V +/-20% ZD205 10-79C12V-DBX DIODE ZENER 12V 1/2W 5%
C220 25-BCB471-M1X CAP. ELEC 470 UF 16V +/-20% ZD207 10-79C12V-DBX DIODE ZENER 12V 1/2W 5%
C221 25-BCB471-M1X CAP. ELEC 470 UF 16V +/-20% ZD208 10-79C12V-DBX DIODE ZENER 12V 1/2W 5%
C222 26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% ZD209 10-79C5V6-DBX DIODE ZENER 5V6 1/2W 5%
C223 25-BDB101-M1X CAP. ELEC 100 UF 25V +/-20%
C224 28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805
C225 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F
WIRE BARE JUMPER
C226 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% J201 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM
C227 25-BCA102-M1X CAP. ELEC 1000 UF 16V +/-20% J203 41-WJ0175-B00 WIRE BARE JUMPER 17.5MM
C228 25-BCB471-M1X CAP. ELEC 470 UF 16V +/-20% J204 41-WJ0100-B00 WIRE BARE JUMPER 10MM
C229 28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805 J206 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM
C230 26-APK102-MEX CAP. CER 1000PF 400VAC +/-20%E J207 41-WJ0100-B00 WIRE BARE JUMPER 10MM
C231 26-ABC102-KBX CAP. CER 1000PF 50V +/-10% B J208 41-WJ0060-B00 WIRE BARE JUMPER 6mm
JP203 19-BB0000-JTX SMD. RES 0 OHM 1/10W +/-5%
CONNECTOR
CON201 46-35063W-03X PIN BASE *3 VH-3A
INDUCTANCE
CON202 46-35199W-04X CONN.PH-4A 4PIN PITCH=2.0MM L201 36-LIF015-XX0 LINE FILTER 2*38MH
CON203 46-31516H-10X HS 2468#24 100 TJC3-10Y/SCN-10 L202 34-A339K0-1IX COIL CHOKE 3.3 UH +/-10%
L203 34-A339K0-1IX COIL CHOKE 3.3 UH +/-10%
FUSE
L204 36-WID339-XX0 COIL WIDTH SG03745
F201 50-02000D-1GS FUSE 2.0AT 250VAC L205 36-WID339-XX0 COIL WIDTH SG03745
7-5
