Philips DVP520 - Page 50

ENCASING & ACCESSORIES PARTS LIST SCREW LIST
1 67-D520R1-0E0 Rear Cabinet 1 11 63-B26080-BF4
S/T Screw B2.6X8 BF
2
2 56-D520L2-0HCxx Right lens 1 14 63-B26080-BF4
S/T Screw B2.6X8 BF
5
3 56-D520L3-xHCxx Door lens 1 20 64-B30060-304
Triangle M/C Screw B3X6
4
4 56-D520W1-0HA
DVD Tray Cosmetic Strip
1 22 64-B30060-302 M/C Screw B3X6 2
5 67-L95097-0A0 PHILIPS LOGO 1 24 63-B30080-BF2 S/T Screw B3X8 BF 4
6 56-D520L1-xHCxx Left Lens 1 25 64-B30060-302 M/C Screw B3X6 4
7 55-D520F*-0HA Front Cabinet 1 26 64-B30060-302 M/C Screw B3X6 2
8 56-D520K1-0HA Power Button 1 28 64-B30060-302 M/C Screw B3X6 2
9 56-D520L4-0HC Power lens 1 29 64-B30100-304
Triangle M/C Screw B3X10
1
10 40-DVP520-SWB1X P.C.B. Switch BD 1
12 58-951170-0H1 ESD Cut Sheet 1
13 56-D520K2-0HA Open/Close Button 1
15 40-DVP520-FBB2X P.C.B. Front CTL BD 1
16 56-D520K3-0HA Play/Stop Button 1
17 40-DVP520-PWC1X P.C.B. Power BD
18 55-D520D1-0HAB1 Front Door 1
19 08-LOADER-005 ASA Loader 1
21 67-D520T1-0E0B1 Top Cover 1
23 67-D520B2-0E0B1 Back Plate 1
27 40-DVP520-MAC2X P.C.B. Main BD
30 62-RCCH10-000 PCB Support 1
31 62-372100-0HA
PCB Bracket H=5MM
1
32 51-DC0165-0CNA4 AC Cord Plug
(forDVP520 /00,/02)
1
51-DC0165-0ANA4
Power Cord L=1650MM
(for DVP520/05)
1
Note: Only the parts mentioned in this list are normal
service spare parts
9-2
No. Part No. Part Name Qty
No. Part No. Part Name Qty
