Philips FC9160 - Parts List

FC9160 /A
PARTS LIST
3-7
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
4322 005 19970
4322 005 17600
4322 000 67810
4322 003 24790
4322 003 24780
4322 000 37300
4322 003 23820
4322 003 24650
4322 009 09560
4322 009 09600
4322 003 24810
4322 003 27910
4322 006 22750
4322 005 20580
4341 003 02390
4322 003 24620
4322 003 24720
4322 003 24600
4322 003 27850
4322 005 17010
4322 003 24690
4322 003 20030
4322 004 92990
4322 001 73460
4322 000 38790
Dustcover / Pr / Slate Grey
Dustcover lock assy
DB detector spring
DB detector / LB / Cool grey
CCC (DB holder)
Triple inletfi lter
Inlet grille
Dustchamber / Black
Handle performer / Slate Grey
Button panel assy / Pr / Slate Grey
Cord winder lever
Control wheel / Select Grey
PCB assy 220-240 V 50/60 Hz
DBFI/Valve assy / Sp.v.
Switch lever
Back panel / Black
Cord outlet / Black
Lower / LB / Back
Lower front / Slate grey
Caster assy / Select grey
Filter cover lock / Select grey
Filter cover / Slate grey
Filter HEPA 13
Exhaust sealing
Silencer 4 wall backpanel
Pos Service code Description
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
42a
43
44
45
46
47
48
49
50
51
52
4322 003 25460
4322 000 38670
4322 000 38770
4322 003 23880
4322 001 73400
4322 006 97940
4322 000 38820
4322 001 73520
4322 003 23870
4322 009 09440
4322 009 09450
4322 009 09460
4322 006 07410
4322 006 07390
4322 003 18850
4322 005 12760
4322 005 20290
4322 004 23360
4322 007 16000
4322 004 23340
4322 001 99120
4322 007 45550
4322 004 22570
4322 003 18870
4322 005 12530
4322 004 22560
4322 004 23260
4322 003 26030
S-Class H-sealing
Silencer 1 wall
Silencer 2 bottom
Motorhousing top inside
Bufferring front ANS-Atlas
Motor Domel 1761 220 - 240 V
Silencer 3 compas
Motor buffer back green
Motor housing bottom ANS
Reel half spring unit (L = 9 m)
Reel half contact unit
Contact ring plate
U.K. / H.K. L = 9.3 m
Euro 4.8 mm pins L = 9.3 m
C. Bend B1
LC Swivel assy
C. Bend B1 / Hose / Swivel assy /
Silver Steel
Hose assy / Silver Steel
Leaf spring assy
3-Piece telescopic tube assy
Coupling bush
Coupling spring
Plumeau assy
Crevicle nozzle
Accessory bridge assy
Small nozzle
Tri-active nozzle
Motor bracket
