1-3
SPECIFICATIONS
GENERAL:
Mains voltage : 110-127V/220-240V Switchable
for /21/21M
: 230 ± 10% for /22/30
: 120 ± 10% for /37
Mains frequency : 50/60Hz
Power consumption : < 1W at ECO Power Standby
:< 25W at Standby (DEMO mode off)
: 175W at Active
Clock accuracy : < 4 seconds per day
Dimension centre unit : 265 x 322 x 390mm
TUNER:
FM
Tuning range : 87.5-108MHz
Grid : 50kHz
100kHz for /37
IF frequency : 10.7MHz ± 25kHz
Aerial input : 75 Ω coaxial
300 Ω click fit for /37
Sensitivity at 26dB S/N : < 7µV
Selectivity at 600kHz bandwidth : > 25dB
Image rejection : > 25dB [> 75dB]
Distortion at RF=1mV, dev. 75kHz : < 3%
-3dB Limiting point : < 8µV
Crosstalk at RF=1mV, dev. 40kHz : > 18dB
MW
Tuning range : 531-1602kHz
530-1700kHz for /21/21M/37
Grid : 9kHz
10kHz for /21/21M/37
IF frequency : 450kHz ± 1kHz
Aerial input : Frame aerial 18.1µH
Sensitivity at 26dB S/N : < 4.4mV/M
Sensitivity at S9/300KHz : > 18dB
IF rejection : > 45dB
Image rejection : > 28dB
Distortion at RF=50mV, M=80% : < 5%
AMPLIFIER:
Output power (6 Ω, 1kHz, 10% THD)
L & R : 2 x 200W RMS /21/22/30
: 2 x 160W FTC /37
Frequency response within -3dB : 63Hz-16kHz
MAX Sound : On / Off
Game Sound : Speed /Punch /Blast /Off
Dynamic Bass Boost (DBB) : DBB 1, 2, 3 & Off
Digital Sound Control (DSC) : Jazz /Rock /Pop /Optimal
Virtual Ambience Control (VAC) : Cyber / Arcade / Hall /
Cinema / Concert
Input sensitivity
Aux in (at 1kHz) : 640mV ± 2dB
Game Port (at 1kHz) : 310mV ± 2dB
USB (at 1kHz) : 830mV at 600 Ω
Output sensitivity
Headphone output at 32 Ω : 700mV ± 2dB (Max. vol.)
5DTC:
Measurement done directly at the connector on the board.
Output Resistance : < 100 Ω
Output Voltage (0dB, 1kHz) : 0.5Vrms ± 1dB (unloaded)
Channel Unbalance : < ±1dB
Channel Separation (1kHz) : > 60dB
Frequency Response (±3dB) : 20Hz-20kHz
Signal to Noise Ratio : > 75dBA
MP3-CD Bit Rate : 32-256 kbps
Sampling Frequencies : 32, 44.1, 48 kHz
USB:
Measurement done directly at the connector on the board.
Output Impedance (1 kHz) : < 1.5 kohm
Output Voltage (0dB, 1kHz) : 830mVrms ± 1.5dB
Channel Unbalance : < ±1dB
Distortion THD (0dB, 1kHz) : < 0.3%
Channel Separation (1kHz) : > 35dB
Frequency Response (±3dB) : 20Hz-20kHz
Signal to Noise Ratio : > 60dBA
[....] Values indicated are for "ECO6 Cenelec Board" only.
