Philips FWM589 - Page 57

8-13
8-13
ELECTRICAL PARTS LIST - MAINS UCD BOARD
MISCELLANEOUS
1701 4822 265 11515 FLEX CONNECTOR 8P
1704 2422 086 02152
!
FUSE 5X20 T 10A 250V
1705 2422 086 02152
!
FUSE 5X20 T 10A 250V
1707 9965 000 07788
!
FUSE RAD LT 2A 250V
1708 9965 000 07788
!
FUSE RAD LT 2A 250V
1710 2422 090 01101 SOC FUSE V 1P F
1711 2422 090 01101 SOC FUSE V 1P F
1712 2422 090 01101 SOC FUSE V 1P F
1713 2422 090 01101 SOC FUSE V 1P F
1902 9965 000 07786
!
FUSE RAD LT 4A 250V /22
1902 2422 086 11115
!
FUSE RAD T 8A 250V /37
1903 9965 000 07789
!
VOLTAGE SELECTOR /21
1904 2422 086 11109
!
FUSE RAD T 6A3 250V/21
1905 2422 132 07519
!
RELAY 1P 12V 16A OZ-SS L
1907 9965 000 07786
!
FUSE RAD LT 4A 250V /21
1950 4822 265 31015
!
MAINS SOCKET /21/22
1951 2422 030 00328
!
MAINS SOCKET /37
CAPACITORS
2700 2020 561 90365 100nF +80/-20% 50V
2701 2020 561 90365 100nF +80/-20% 50V
2702 4822 124 41584 100uF 20% 10V
2703 4822 124 40207 100uF 20% 25V
2704 5322 121 42578 100nF 5% 250V
2705 5322 121 42578 100nF 5% 250V
2706 2022 020 00737 6800uF 20% 50V
2707 5322 121 42578 100nF 5% 250V
2708 2022 020 00737 6800uF 20% 50V
2709 5322 121 42578 100nF 5% 250V
2710 5322 121 42578 100nF 5% 250V
2711 2022 020 00782 6800uF 20% 35V
2712 2020 012 93745 10000uF 20% 16V
2713 4822 124 81151 22uF 50V
2714 4822 126 12785 47nF 50V
2715 2020 012 93741 100uF 20% 100V
2900 4822 121 43526 47nF 5% 250V
2902 2222 336 19106
!
22nF 20% 275V
2905 4822 121 51387 10nF 20% 16V
2906 4822 121 51387 10nF 20% 16V
2907 4822 124 40255 100uF 20% 63V
2908 4822 121 10512
!
220nF 20% 275V /22
2909 4822 126 13589
!
470nF 20% 275V /21/37
2913 4822 126 12785 47nF 50V
2916 2020 561 90365 100nF +80/-20% 50V
2917 4822 126 11714 4,7nF 20%
2918 4822 126 14088
!
2,2nF 20% 250V
RESISTORS
3700 4822 052 10101
!
100R 5% 0,33W
3701 4822 052 10101
!
100R 5% 0,33W
3702 4822 116 83884 47k 5% 0,5W
3703 4822 116 52243 1k5 5% 0,5W
3704 4822 116 52283 4k7 5% 0,5W
3705 4822 050 23303 33k 1% 0,6W
3706 4822 116 52219 330R 5% 0,5W
3707 4822 052 10479
!
47R 5% 0,33W
3708 4822 116 52283 4k7 5% 0,5W
3709 4822 116 52269 3k3 5% 0,5W
3710 4822 116 52269 3k3 5% 0,5W
3711 4822 116 83872 220R 5% 0,5W
3900 4822 053 21106
!
10M 5% 0,5W /37
3901 4822 050 21003 10k 1% 0,6W
3902 4822 050 24705 4M7 1% 0,6W
3903 4822 116 52219 330R 5% 0,5W
3904 4822 116 52234 100k 5% 0,5W
3906 4822 116 83883 470R 5% 0,5W
3909 4822 116 52272 330k 5% 0,5W
3912 4822 053 21106
!
10M 5% 0,5W
3915 4822 116 83866 1M 5% 0,5W
3916 4822 116 52256 2k2 5% 0,5W
3917 4822 116 52234 100k 5% 0,5W
COILS & FILTERS
5903 4822 157 11628
!
FIL MAINS
5904 2422 549 45157
!
TRAFO STANDBY 3A1631N
5929 4822 157 53473 IND FXD 1000uH 10%
5930 4822 157 52333 IND FXD 100uH 5%
5931 4822 157 53473 IND FXD 1000uH 10%
DIODES
6701 4822 130 30621 1N4148
6702 4822 130 30621 1N4148
6703 4822 130 30621 1N4148
6704 4822 130 30621 1N4148
6705 4822 130 30621 1N4148
6706 4822 130 30621 1N4148
6707 4822 130 30621 1N4148
6708 4822 130 30621 1N4148
6709 4822 130 30621 1N4148
6710 4822 130 30621 1N4148
6711 4822 130 34173 BZX79-C5V6
6712 9322 197 92682 BRIDGE GBJ10D
6714 4822 130 30621 1N4148
6715 4822 130 34142 BZX79-C33
6716 4822 130 34382 BZX79-C8V2
6718 4822 130 31878 1N5392
6719 4822 130 31878 1N5392
6720 4822 130 31878 1N5392
6721 4822 130 31878 1N5392
6722 4822 130 31878 1N5392
6723 4822 130 31878 1N5392
6900 4822 130 31878 1N4003G
6901 4822 130 31878 1N4003G
6902 4822 130 30621 1N4148
6905 4822 130 31878 1N4003G
6906 4822 130 31878 1N4003G
6912 4822 130 34145 BZX79-C39
6913 4822 130 31878 1N4003G
6916 4822 130 30621 1N4148
6917 4822 130 31878 1N4003G
TRANSISTORS & INTEGRATED CIRCUITS
7700 4822 130 40981 BC337-25
ELECTRICAL PARTS LIST - REGULATOR UCD BOARD
0002 3139 114 75361 HOLDER IC
0005 3139 114 71010 STOPPER HEATSINK
CAPACITORS
2500 4822 126 14585 100nF 10% 50V
2501 4822 124 81286 47uF 20% 16V
2502 4822 126 14585 100nF 10% 50V
2507 2222 580 15649 100nF 10% 50V
2508 4822 126 14585 100nF 10% 50V
2509 4822 124 81286 47uF 20% 16V
2510 4822 124 81286 47uF 20% 16V
2511 4822 124 41643 100uF 20% 16V
2512 4822 124 41643 100uF 20% 16V
2513 4822 124 80231 47uF 20% 16V
RESISTORS
3500 4822 051 30121 120R 5% 0,062W
3501 4822 051 30151 150R 5% 0,062W
3502 4822 051 30471 470R 5% 0,062W
3503 4822 051 30471 470R 5% 0,062W
3510 4822 051 30181 180R 5% 0,062W
3511 4822 051 30152 1k5 5% 0,062W
3512 4822 051 30479 47R 5% 0,062W
3513 4822 116 83872 220R 5% 0,5W
MISCELLANEOUS
3514 4822 052 10568
!
5R6 5% 0,33W
3515 4822 116 83883 470R 5% 0,5W
3516 4822 050 11002 1k 1% 0,4W
3517 4822 117 12063 NTC DC 5W 10k 5%
3519 4822 051 30682 6k8 5% 0,062W
3520 4822 051 30153 15k 5% 0,062W
3522 4822 051 30102 1k 5% 0,062W
3523 4822 051 30102 1k 5% 0,062W
3524 4822 117 13632 100k 1% 0,62W
DIODES
6501 4822 130 34174 BZX79-C4V7
6502 4822 130 11397 BAS316
6503 4822 130 11397 BAS316
6504 4822 130 11397 BAS316
TRANSISTORS & INTEGRATED CIRCUITS
7500 4822 209 81351 IC LM317P
7504 4822 209 81351 IC LM317P
7505 4822 130 41246 BC327-25
7506 5322 130 60159 BC847B
Note : Only the parts mentioned in this list are normal
service spare parts.
ELECTRICAL PARTS LIST - MAINS UCD BOARD
7701 4822 130 41327 BC327-40
7702 4822 130 41327 BC327-40
7900 4822 130 44568 BC557B
7901 4822 130 40959 BC547B
7902 4822 130 40855 BC337-40
7903 4822 130 44568 BC557B
Note : Only the parts mentioned in this list are normal
service spare parts.
ELECTRICAL PARTS LIST - SPEAKER UCD BOARD
MISCELLANEOUS
1300 4822 267 31176 SOC CLICK 4P
CAPACITORS
2300 4822 121 41857 10nF 5% 250V
2301 4822 121 41857 10nF 5% 250V
2302 4822 121 41857 10nF 5% 250V
2303 4822 121 41857 10nF 5% 250V
2304 4822 121 43526 47nF 5% 250V
2305 4822 121 43526 47nF 5% 250V
Note : Only the parts mentioned in this list are normal
service spare parts.
