Fitting a plug
Connections - Applicable to U.K. only
Important
WARNING - THIS APPLIANCE MUST BE EARTHED
The wires in this mains lead are coloured in accordance with the
following code:
GREEN AND YELLOW - EARTH
BLUE - NEUTRAL
BROWN - LIVE
As the colours of the wires in the mains lead of this appliance may not
correspond with the markings identifying the terminals in your plug,
proceed as follows:
The wire which is coloured GREEN AND YELLOW must be connected
to the terminal which is marked with the letter "E" or by the earth
symbol E or coloured GREEN or GREEN AND YELLOW.
The wire which is coloured BLUE must be connected to the terminal
which is marked with a letter "N" or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal
which is marked with the letter "L" or coloured RED.
Note: If the terminals of the plug are unmarked or if you are in any
doubt, consult a qualified electrician.
If a 13 Amp. 3-pin plug is fitted, it must be an "approved" plug,
conforming to BS 1363-1986.
If a (BS 1363) 13 Amp. plug is used, this must be fitted with a 3 Amp.
fuse.
