Philips HearLink - Page 82

82
About Getting started Daily use Options Warnings More info
ITC/ITE HS/ITE FS
Measured according to American National Standard ANSI S3.22-2014,
IEC 60118-0:2015 and IEC 60318-5:2006
Supply voltage: Zinc-Air
Technical Data
0 dB SPL ref. 20 μPa HearLink 9030
HearLink 7030,
5030, 3030 & 2030
OSPL90
Peak 126 dB SPL 126 dB SPL
HF Average 123 dB SPL 123 dB SPL
Full-on Gain
Peak 64 dB 64 dB
HF Average 60 dB 60 dB
Reference Test Gain 46 dB 46 dB
Frequency Range 100-5400 Hz 100-5400 Hz
Total Harmonic
Distortion
500 Hz <2 % <2 %
800 Hz <2 % <2 %
1600 Hz <2 % <2 %
Equivalent Input
Noise Level
(omni/dir) 15/ 30 dB SPL 15/ 30 dB SPL
HF Average SPLITS (left/right ear) 105/105 dB SPL 105/105 dB SPL
Attack Time 8 ms 7 ms
Release Time 21 ms 21 ms
