Philips HQ4819/16 - Replacement of Shaving Heads; Shaving Head Replacement Procedure

Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with HQ4
Ç Philips shaving heads only.
1 Switch off the shaver, remove the mains plug
from the wall socket and pull the appliance plug
out of the shaver.
2 Press the release button (1) and remove the
shaving unit (2).
3 To remove the retaining frame, push the sides
of the central spring towards each other (1).
Then lift the retaining frame out of the shaving
unit (2).
4 Slide the shaving heads out of the retaining
frame.
5 Slide the new shaving heads into the retaining
frame.
6 Put the retaining frame back into the shaving
unit.
7 Put the shaving unit back onto the shaver.
ENGLISH 11
