Philips HR7600 - Disassembly and Re-assembly Advice; Repair Instructions; Optional Accessories

HR7600 / HR7605
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- No specific issues
REPAIR INSTRUCTIONS
Use grease 4822 390 20004 to lubricate the parts of the
gearbox.
2
3
3,50 ± 0,15
Note:
Support the rotorshaft to prevent forces on the motor
bearings, during the assembly of the pinion on the rotorshaft.
OPTIONAL (accessories)
- No specific issues
M
Thermal
cut-out
Pulse - 0 - 1
Microswitch
Safety
switch
C
AC
2-4
