Philips HR7600 - Parts List and Exploded View

HR7600 / HR7605
PARTS LIST & EXPLODED VIEW
6
4
3
2
1
5
11
10
9
12
8
7
3-4
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
11
12
4203 065 63040
4203 065 63100
4203 065 63060
4203 065 63050
4203 065 64700
4203 065 63090
4203 065 63110
4822 276 31591
4203 065 59770
4203 065 63080
4203 065 63030
4203 065 63120
Upper housing assy
Gearbox / motor assy
Gearbox assy
Release lever L + R
Bottom housing
(HR7600 + HR7605)
Coupling piece
Micro-switch
Wire connector for two wires
Rubber plate
Detection piece
Cordset
Rubber buffer
