Philips HR7735 - Technical Information; Parts List

HR7735/55
2-8
- Motor : Universal, radio/TV interference suppressed
- Power consumption : 700 Watt max.
- Voltage and frequency : 220 V - 240 V, 50 Hz
- Cord set : 100 cm, double insulated with moulded on plug
- Speed setting : 2 speeds & pulse
- Bowl capacity : 3,6 L dry ingredients, 1,8 L liquid ingredients
- Blender capacity : 2,0 L dry ingredients, 1,5 L liquid ingredients
Materials used
- Bowl, lid, blender jar, blender cup, safety cap : SAN
- Housing, blender lid, pusher, inlay bowl : PP
and blender handle, emulsifying disc,
kneading accessory
- Insert holder : ABS
Colours
- Bright white and sunflower orange, clear transparent bowl and jar.
Preliminary data No. of pcs Weight (kg) Dimensions (mm)
- F-box 1 5,62 390 x 290 x 400
TECHNICAL INFORMATION
PARTS LIST
Pos Service code Description
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
4203 065 65480
4203 065 65150
4203 035 85120
4203 065 65310
4203 035 85130
4203 035 85300
4203 035 85140
4203 035 85150
4203 065 65270
4203 035 85160
4203 065 65180
4203 035 85380
4203 065 65390
4203 065 65190
4203 065 65230
4203 065 65200
4203 065 64020
4203 065 64000
4203 065 65400
4203 065 65170
4203 065 65450
4203 065 65290
Housing Cap
Screw cap (3 pcs.)
Housing Top
Coupling Toolholder
Toolholder
Blender Coupling HR7735/55
Power Knob
Quick Clean Knob
Spring - Quick Clean Knob
Cordset Holder
Detection Lever - Jar
Housing printed HR7735/55
Spring Bowl Detection
Horizontal Lever
PCB Frame Assy
PCB Assy
Cordset EU
Cordset UK
Cordset Swiss
Airtunnel
Motor Assy
Decoupling lever
Pos Service code Description
23
24
25
26
27
29
30
35
36
37
38
45
46
47
50
52
54
55
62
63
64
4203 035 85390
4203 065 65780
4203 065 65770
4203 065 65420
4203 065 65440
4203 065 65410
4203 065 65460
4203 035 85190
4203 035 85200
4203 065 65630
4203 035 85210
4203 065 65560
4203 035 85240
4203 035 85250
4203 065 61540
4203 065 61560
4203 065 61570
4203 035 85260
4203 035 85270
4203 065 65490
4203 035 85370
Bottom Assy HR7735-45/55
Retaining Ring
Washer
Coupling Fork
Coupling Assy
Toothed Wheel Assy
Belt
Pusher Chopper Bowl
Chopping Bowl Lid
Rubber Sealing Ring
Chopper Bowl Assy
Stopper lid - Jar
Jar Lid
Blender Jar Assy
Slicing Insert medium
Shredding Insert medium
Granulating Insert (Reibekuchen)
Insert Holder Assy
Plastic Kneader
Chopping Knife Assy
Emulsifying Disc
= changed
