Philips HTB3560/12 Service Manual

USB
 Compatibility: Hi-Speed USB (2.0)
 Class support: USB Mass Storage Class
(MSC)
 File system: FAT16, FAT32, NTFS
 Maximum memory support: < 160 GB
Main unit
 Power supply:
 Europe/China/Russia/India: 220-240
V~, 50 Hz
 /DWLQ$PHULFD$VLD3DFLÀF9a
50-60 Hz
 Power consumption: 60 W
 6WDQGE\SRZHUFRQVXPSWLRQ:
 Dimensions (WxHxD): 360 x 58 x 325
mm
 Weight: 2.4 kg
Subwoofer
 Output power: 50 W RMS (30% THD)
 Impedance: 4 ohm
 Speaker drivers: 133 mm (5.25") woofer
 Dimensions (WxHxD):
160 x 265 x 265 mm
 Weight: 2.50 kg
Speakers
Center speaker:
 Output power: 50 W RMS (30% THD)
 Speaker impedance: 4 ohm
 Speaker drivers: 1 x 63.5 mm (2.5") woofer
 Dimensions (WxHxD): 84.5 x 89 x 89 mm
 Weight: 0.27 kg
Front speaker:
 Output power: 2 x 50 W RMS (30% THD)
 Speaker impedance: 4 ohm
 Speaker drivers: 1 x 63.5 mm (2.5") woofer
 Dimensions (WxHxD): 84.5 x 159 x 80
mm
 Weight: 0.35 kg/each
Rear speaker:
 Output power: 2 x 50 W RMS (30% THD)
 Speaker impedance: 4 ohm
 Speaker drivers: 1 x 63.5 mm (2.5") woofer
 Dimensions (WxHxD): 84.5 x 89 x 89 mm
 Weight: 0.27 kg/each
Remote control batteries
 2 x AAA-R03-1.5 V
Laser
 Laser Type (Diode): InGaN/AIGaN (BD),
AIGaInP (DVD/CD)
 Wave length: 405 +7 nm/-7 nm (BD), 655
+10 nm/-10 nm (DVD), 790 +10 nm/-20
nm (CD)
 Output power (Max. ratings): 20 mW
(BD), 6 mW (DVD), 7 mW (CD)
1-4

Philips HTB3560/12 Specifications

Sound System

center speaker output power	50 W
cube speaker output power	2 x 50 W
satellite speaker output power	2 x 50 W
subwoofer output power	50 W
total power RMS at 30% THD	300 W

Loudspeakers

drivers per cube speaker	1 x 2.5" woofer
cube speaker frequency range	150 - 20k Hz
cube speaker impedance	4 ohm
drivers per satellite speaker	1 x 2.5" woofer
satellite speaker impedance	4 ohm
satellite speaker frequency range	150 - 20k Hz
subwoofer driver	1 x 5.25" woofer
subwoofer frequency range	20 - 150 Hz
subwoofer impedance	4 ohm

Connectivity

front connections	Music iLINK, USB
rear connections	AUX in, Click-fit Speaker Connectors, Composite video (CVBS) output, Digital optical in, Ethernet, Fixed FM Antenna, HDMI 1.4 output (ARC)

Power

power consumption	60 W
power supply	220-240V, 50Hz
standby power consumption	< 0.5 W

Dimensions and Weight

main unit dimensions	360 x 58 x 325 mm
main unit weight	2.40 kg
center speaker dimensions	84.5 x 89 x 89 mm
center speaker weight	0.30 kg
center speaker cable length	2 m
front speaker dimensions	85 x 160 x 95 mm
front speaker weight	0.28 kg
front speaker cable length	3 m
rear speaker dimensions	84.5 x 159 x 80 mm
rear speaker weight	0.30 kg
rear speaker cable length	7 m
subwoofer dimensions	160 x 267.5 x 265 mm
subwoofer cable length	2 m
subwoofer weight	2.5 kg
packaging dimensions	520 x 310 x 377 mm
weight including packaging	8.75 kg
