Philips HTS3531/05 - Page 2

1-2
PCB BOARD LOCATION:
Version Variation
/05 /12 /51 /79 /94 /98
Output Power-300W X XXXXX
Voltage(220~240V) X XXXX
Voltage(110~240V) X
MP3 LINK X XXXXX
Repair Scenario Matrix
/05 /12 /51 /79 /94 /98
Main Board C CCCCC
Front Control Board C CCCCC
Amplifier Board C CCCCC
Power Board C CCCCC
*Bd:Board Level Replacement
*C:Component Level Repair
Type/Versions
Board in used
HTS3531
Type/Versions
Features
HTS3531
MAIN BOARD
AMPLIFIER BOARD
POWER BOARD
FRONT CONTROL
BOARD
LOADER
