Philips LC7.2E User Manual

Spare Parts List
EN 110 LC7.2E LA10.
3639 4822 117 13573 4 x 47Ω 5%
3640 4822 117 13573 4 x 47Ω 5%
3641 4822 117 13573 4 x 47Ω 5%
3642 4822 117 13573 4 x 47Ω 5%
3643 4822 117 13573 4 x 47Ω 5%
3645 4822 117 13546 47Ω 5% 0402
3646 4822 117 13546 47Ω 5% 0402
3710 2322 702 60511 510Ω 5% 0603
3711 4822 117 13606 10kΩ 5% 0.01W 0402
3712 4822 117 11297 100kΩ 5% 0.1W
3713 3198 031 01090 10Ω 5% 0.01W 0402
3714 3198 031 02720 2.7kΩ 5% 0.01W 0402
3715 3198 031 04720 4.7kΩ 5% 0402
3716 4822 117 13548 1kΩ 5% 0402
3717 3198 031 01820 1.8kΩ 5% 0.01W 0402
4311 4822 117 13605 Jumper 0402
4315 4822 117 13605 Jumper 0402
4316 4822 117 13605 Jumper 0402
4317 4822 117 13605 Jumper 0402
4401 4822 117 13605 Jumper 0402
b
5710 2422 535 94134 10μH 20% 0805
5711 2422 536 00671 10μH 20%
5712 2422 549 43769 Bead 30Ω at 100MHz
5713 2422 549 43769 Bead 30Ω at 100MHz
5714 2422 549 43769 Bead 30Ω at 100MHz
5715 2422 549 43769 Bead 30Ω at 100MHz
5716 2422 549 43769 Bead 30Ω at 100MHz
5717 2422 549 43769 Bead 30Ω at 100MHz
5718 2422 549 43769 Bead 30Ω at 100MHz
5719 2422 549 43769 Bead 30Ω at 100MHz
5720 2422 549 43769 Bead 30Ω at 100MHz
5721 2422 549 43769 Bead 30Ω at 100MHz
5722 2422 549 43769 Bead 30Ω at 100MHz
5723 2422 549 43769 Bead 30Ω at 100MHz
5724 2422 549 43769 Bead 30Ω at 100MHz
d
6101 4822 130 11416 PDZ6.8B
6102 4822 130 11416 PDZ6.8B
6210 4822 130 11525 1SS356
6211 4822 130 11416 PDZ6.8B
6701 4822 130 11397 BAS316
ce
7101 9322 246 49671 GM1601-LF-CF
7201 For SW see item 0823
7203 9322 215 39685 PST596JN
7301 9322 210 59668 THC63LVDF84B
7601 9322 235 50668 K4D263238I-UC50
7701 9322 160 70668 SI4936ADY
7710 9322 182 77668 L6910
7713 9322 160 50668 LD1117DT25
7714 9322 217 28668 LD1117DT18
IR LED Panel [J]
Various
1M01 2422 025 10775 Connector 3p m
1M01 2422 025 18146 Connector 3p m Wh
1M20 2422 025 18151 Connector 7p m Wh
1M20 4822 265 41343 Connector 7p m
g
2001 2020 552 00134 22μF 20% 6.3V 0805
f
3010 4822 051 30331 330Ω 5% 0.062W
3011 4822 051 30682 6.8Ω 5% 0.062W
3012 4822 051 30682 6.8Ω 5% 0.062W
3013 4822 117 12968 820Ω 5% 0.62W
3014 4822 051 30103 10kΩ 5% 0.062W
3019 4822 051 30151 150Ω 5% 0.062W
3020 4822 051 30151 150Ω 5% 0.062W
4001 4822 051 30008 Jumper 0603
4002 4822 051 30008 Jumper 0603
4004 4822 051 30008 Jumper 0603
4005 4822 051 30008 Jumper 0603
4010 4822 051 30008 Jumper 0603
4012 4822 051 30008 Jumper 0603
4015 4822 051 30008 Jumper 0603
4017 4822 051 30008 Jumper 0603
4019 4822 051 30008 Jumper 0603
d
6010 9322 243 77676 LED L-174A2PBC
6011 9322 244 07676 LED L-174A2IT-TNB5-19
6012 4822 130 11148 UDZ4.7B
ce
7010 9322 243 06671 IR Receiver
7011 5322 130 60159 BC846B
7012 5322 130 60159 BC846B
