Technical Specifications, Connections, and Chassis Overview
EN 5LC7.2E LA 1.
Figure 1-5 PWB/CBA locations (37” and 42” models without 1080p module)
Figure 1-6 PWB/CBA locations (42” models with 1080p module)
H_16940_008.eps
050307
B
POWER SUPPLY UNIT
D
SIDE I/O PANEL
SMALL SIGNAL
BOARD
J
LED PANEL
E
CONTROL PANEL
G_16860_092.eps
150307
B
POWER SUPPLY UNIT
D
SIDE I/O PANEL
SMALL SIGNAL
BOARD
F
1080p PANEL
J
LED PANEL
E
CONTROL PANEL
