Alignments
EN 85LC7.2E LA 8.
Table 8-4 Option codes at bit level (OP5-OP7)
Option Byte & Bit Dec. Value Option Name Description
Byte OP5
Bit 7 (MSB) 128 NVM_CHECK ON = NVM (range) checking is available
OFF = NVM (range) checking is not available
Bit 6 64 Reserved Not Used (Reserved)
Bit 5 32 Reserved Not Used (Reserved)
Bit 4 16 MP_ALIGN ON = Using multi-point alignment for Gamma & White Point
OFF = Using old way for Gamma (pre-defined) & WP alignment
Bit 3 8 SYS_RECVRY ON = System Recovery is available
OFF = System Recovery is not available
Bit 2 4 SL_WIRED ON = BDS Smart Loader Wired is available
OFF = BDS Smart Loader Wired is not available
Bit 1 2 HOTEL ON = Hotel/BDS is available
OFF = Hotel/BDS is not available
Bit 0 (LSB) 1 SS_DEMO ON = Split Screen Demo is available
OFF = Split Screen is not available
Total DEC Value
Byte OP6
Bit 7 (MSB) 128 Reserved Not Used (Reserved)
Bit 6 64 Reserved Not Used (Reserved)
Bit 5 32 Reserved Not Used (Reserved)
Bit 4 16 Reserved Not Used (Reserved)
Bit 3 8 TUNER PROFILE 0 = ATV_EU_PHILIPS UV1318S/AIH-3
1 = ATV_EU_Panasonic EN57K28G3F
2 = DTV_EU_PHILIPS TD1316AF/IHP-2
4 = ATV_AP_PHILIPS UV1316E/AIH-4
5 = ATV_AP_Tuner2 (Reserved)
6 = ATV_CHINA_ALPS TEDE9-286B
7 = ATV_CHINA_Tuner2 (Reserved)
8 = ATV_LATAM_PHILIPS UV1338/AIH-4
9 = ATV_LATAM_Tuner2 (Reserved)
10 = DTV_CHINA_Tuner1 (Reserved)
11 = DTV_CHINA_Tuner2 (Reserved)
12 = Not Used (Reserved)
13 = Not Used (Reserved)
14 = Not Used (Reserved)
15 = Not Used (Reserved)
Bit 2 4
Bit 1 2
Bit 0 (LSB) 1
Total DEC Value
Byte OP7
Bit 7 (MSB) 128 Reserved Not Used (Reserved)
Bit 6 64 Reserved Not Used (Reserved)
Bit 5 32 Reserved Not Used (Reserved)
Bit 4 16 CABINET PROFILE 0 = Cabinet_Profile_26_LCD_ME7
1 = Cabinet_Profile_32_LCD_ME7
2 = Cabinet_Profile_37_42_47_LCD_ME7
3 = Cabinet_Profile_42_50_PDP_ME7
4 = Cabinet_Profile_26_LCD_ME5P
5 - 32 = Reserved
Bit 3 8
Bit 2 4
Bit 1 2
Bit 0 (LSB) 1
Total DEC Value
