Technical Specifications, Connections, and Chassis Overview
EN 5LC7.5E LA 1.
1.3 Chassis Overview
Figure 1-4 PWB/CBA locations (32" sets)
Figure 1-5 PWB/CBA locations (42" models)
H_17370_052.eps
090807
B
MAIN SUPPLY UNIT
D
SIDE I/O PANEL
SMALL SIGNAL
BOARD
J
LED PANEL
E
CONTROL BOARD
H_17370_054.eps
090807
B
MAIN SUPPLY UNIT
D
SIDE I/O PANEL
SMALL SIGNAL
BOARD
J
LED PANEL
E
CONTROL BOARD
