Alignments
EN 91LC7.5E LA 8.
Table 8-4 Option codes at bit level (OP5-OP7)
Option Byte & Bit Dec. Value Option Name Description
Byte OP5
Bit 7 (MSB) 128 NVM_CHECK ON = NVM (range) checking is available OFF = NVM (range) checking is not available
Bit 6 64 DNM ON = DNM is available OFF = DNM is not available
Bit 5 32 SUBWOOFER ON = Subwoofer is available OFF = Subwoofer is not available
Bit 4 16 MP_ALIGN ON = Using multi-point alignment for Gamma & White Point OFF = Using old way for Gamma (pre-
defined) & WP alignment
Bit 3 8 SYS_RECVRY ON = System Recovery is available OFF = System Recovery is not available
Bit 2 4 ED_HD_DNM ON = DNM not available on ED and HD signal OFF = DNM available on ED and HD signal
Bit 1 2 HOTEL ON = Hotel/BDS is available OFF = Hotel/BDS is not available
Bit 0 (LSB) 1 SS_DEMO ON = Split Screen Demo is available OFF = Split Screen Demo is not available
Total DEC Value
Byte OP6
Bit 7 (MSB) 128 BACKLIGHT_BOOST ON = iLAB Backlight boost feature is available OFF = iLAB Backlight boost feature is not available
Bit 6 64 STATIC _DIMMING ON = iLAB Static Dimming feature is available OFF = iLAB Static Dimming feature is not available
Bit 5 32 CEC ON = CEC feature available OFF = CEC feature not available
Bit 4 16 AUTO_HDMI ON = Auto HDMI feature available OFF = Auto HDMI feature not available
Bit 3 8 TUNER PROFILE 0 = ATV_EU_PHILIPS UV1318S/AIH-3 1 = ATV_EU_Panasonic EN57K28G3F2 =
DTV_EU_PHILIPS TD1316AF/IHP-24 = ATV_AP_PHILIPS UV1316E/AIH-45 = ATV_AP_Tuner2
(Reserved)6 = ATV_CHINA_ALPS TEDE9-286B7 = ATV_CHINA_Tuner2 (Reserved)8 =
ATV_LATAM_PHILIPS UV1338/AIH-4 9 = ATV_LATAM_Tuner2 (Reserved)10 =
DTV_CHINA_Tuner1 (Reserved)11 = DTV_CHINA_Tuner2 (Reserved)12 = Not Used
(Reserved)13 = Not Used (Reserved)14 = Not Used (Reserved)15 = Not Used (Reserved)
Bit 2 4
Bit 1 2
Bit 0 (LSB) 1
Total DEC Value
Byte OP7
Bit 7 (MSB) 128 Reserved Not Used (Reserved)
Bit 6 64 Reserved Not Used (Reserved)
Bit 5 32 Reserved Not Used (Reserved)
Bit 4 16 CABINET PROFILE 0 = Cabinet_Profile_26_LCD_ME7 1 = Cabinet_Profile_32_LCD_ME7 2 =
Cabinet_Profile_37_42_47_LCD_ME73 = Cabinet_Profile_42_50_PDP_ME7 4 =
Cabinet_Profile_26_LCD_ME5P 5 = Cabinet_Profile_52_LCD_ME7 6 =
Cabinet_Profile_Supernova7- 32 = Reserved
Bit 3 8
Bit 2 4
Bit 1 2
Bit 0 (LSB) 1
Total DEC Value
