Automatic shutter: up to 1/100,000 sec.
Selectable
2
): ON, OFF, Flickerless
Manual shutter: 1/60 up to 1/10,000
Selectable
2
):
Auto Black: ON, OFF
Selectable
2
):
Black level: 15 fixed levels
Contouring: H and V symmetrical,
Selectable
2
): 15 fixed levels,Automatic and OFF
Compression: White Compression
Selectable
2
): 15 fixed levels and OFF
Gamma: Contrast Enhancement
Selectable
2
): 15 fixed level, 0.25 up to 1
Video Output
Video output 1: BNC isolated from mechanical earth, 75 Ω,AC coupled,
nominal 1 V[
p-p
] CCIR or EIA composite,
Video output 2: 4 pin S-VHS connector,AC coupled
Balanced output. 2 V[
p-p
] into 150 Ω. Unbalance -20 dB at
5 MHz
Synchronization: Internal crystal reference, Line-locked, H/V-lock, ext V-lock
Sync. Input BNC isolated from mechanical earth
Input impedance: Selectable
2
): 75 Ω or >10 kΩ AC coupled
External H/V lock: Nominal CVBS 1 V[
p-p
] (min. 150 mV, max. 600 mV)
External V-lock: Positive V-pulse, 8%-50% duty cycle, Standard 5 V, Cmos level
Capture time: ≤2 s.
Serial Input/Output: Sub D, 9-pole connector, RS 232 Selectable
2
): 1200, 2400,
4800 baud. Connector pinnings:TX=2, Rx=3, Ground=5
User input: Switch to Mode 3, Mode select input=1, Ground=5. Pull-up
10 kΩ to +5V
Selectable
2
): Active low or active high or disable.
Lens:
DC-iris Control & Drive 40 mA max
Video-iris 9-10 Vdc 40 mA max.Video drive level 1 V[
p-p
]
2
) Selection by PC software LTC0650/00
16
10
Specifications
9.2.7 H Phase
This function is active when the camera operates with external synchronisation (H+V).
Use the H-phase setting to adjust Horizontal timing differences when cameras are H-V
synchronised. Input standard CVBS synchronisation signals.
9.2.8 ext V Phase
This function is active when the camera operates with external synchronisation.
(External V)
Use the extV phase setting to adjust V phase differences when cameras are used in a
system. Input; Positive V-pulse, 8-50% duty cycle, 5 V CMOS level.
LTC 0500/10/50 models, CCIR
Pick-up Device: 752 (H) x 582 (V) active pixels, Interline Transfer CCD.
Scanning Area: 7.95 (H) x 6.45 (V) mm. Equivalent to 1/2” diagonal scanning area.
Scanning PAL: 625 lines / 50 fields / 25 frames, interlaced
Horizontal: 15.625 kHz
Vertical: 50 Hz
LTC 0500/20/60 models, EIA
Pick-up Device: 768 (H) x 494 (V) active pixels, Interline Transfer CCD.
Scanning Area: 7.95 (H) x 6.45 (V) mm. Equivalent to 1/2” diagonal scanning area.
Scanning PAL: 525 lines / 60 fields / 30 frames, interlaced
Horizontal: 15.734 kHz
Vertical: 60 Hz
Horizontal Resolution: 550 TVL
MTF: ≥ 50 % at 5 MHz
Sensitivity: Usable Picture Full Video
Scene illumination:
1
) fc 0.005 0.04
lx 0.05 0.4
Imager illumination: fc 0.0006 0.005
lx 0.006 0.05
1
) for f/1.2 lens, 89% scene reflectance and 18 dB AGC
Signal-to-Noise: 50 dB at 0.4 lux (0.04 fc) sensor illumination
(Unified weighting filter in accordance with CCIR Rec. 567)
AGC: 18 dB
Selectable
2
): 24 dB
