ELECTRICAL PARTSLIST
MAIN BOARD ASSEMBL
Y
D2 996510000323 SMD DIODE BAS316
D6 994000003938 RECTIFIER DIODE RL-202
D7 994000003938 RECTIFIER DIODE RL-202
D8 994000003938 RECTIFIER DIODE RL-202
D9 994000003938 RECTIFIER DIODE RL-202
IC1 996510006827 IC (SANYO) LA6541NHL-TE-L-E
IC2 996500039806 IC ET2314 (SOP28)
IC3 996510006828 IC (SANYO) LA9242M-MPB-E
IC4 996510006829 IC (SANYO) LC78602RE-8616
Q1 996510000315 SMD TRANSISTORS BC807-25
Q10 996510010910 TRANSISTOR ST8050C
Q11 994000004145 TRANSISTORS B772Y (160-320)
Q12 996510010292 SMD TRANSISTORS MMBT3904
Q13 996510000315 SMD TRANSISTORS BC807-25
Q14 996510003996 TRANSISTORS KTA1273
Q15 996510010910 TRANSISTOR ST8050C
Q19 996510010910 TRANSISTOR ST8050C
Q2 996510008369 TRANSISTORS MMBT8050D (SOT23)
Q21 996510010292 SMD TRANSISTORS MMBT3904
Q22 994000004145 TRANSISTORS B772Y (160-320)
Q25 996510010292 SMD TRANSISTORS MMBT3904
Q3 996510008369 TRANSISTORS MMBT8050D (SOT23)
Q4 996510008369 TRANSISTORS MMBT8050D (SOT23)
Q5 996510010292 SMD TRANSISTORS MMBT3904
Q5 996510010910 TRANSISTOR ST8050C
Q6 996510000315 SMD TRANSISTORS BC807-25
Q7 996510010292 SMD TRANSISTORS MMBT3904
Q9 994000004145 TRANSISTORS B772Y (160-320)
U101 994000003636 IC D8227 DIP
U2 994000000253 IC (SAMSUNG) KA7808
U201 994000000253 IC (SAMSUNG) KA7808
U202 994000002839 IC LM1117S-3.3
U203 996510013793 IC NCP803SN293T1G
U204 996510013794 IC XC6210A122 1.2V
U33 994000001357 IC LM78L05-AC
X1 994000004551 CRYSTAL 16.9344MHZ +-20PPM
S001 994000003093 CD DOOR SWITCH 1P1T DTS-03
J44 996500042462 FXDIND BEAD 100MHz 80R
CON3 996510005450 SPK JACK PT-22V11A
F1
!
994000000586 GLASS FUSE W/LEAD 3.15A/250V
JACK1 994000004369 PHONE JACK TC38-063-05-0
JACK2 996510000889 PHONE JACK TC38-060-01 RING
L2 996500042462 FXDIND BEAD 100MHz 80R
L22 996510000885 CHOKE COIL 47UH W/PLASTIC TUBE
L23 996510000885 CHOKE COIL 47UH W/PLASTIC TUBE
L3 996500042462 FXDIND BEAD 100MHz 80R
8 - 1
