Philips MCM190/22 - Controls; Controls on the system and remote control; Controls available on the remote control only

10
English
Controls (illustrations on page 3)
Controls on the system and
remote control
1 STANDBY ON y
– switches the system to standby/on.
2 iR SENSOR
– infrared sensor for remote control.
3 CLOCK SET
– sets the clock function.
4 PROGRAM
for CD ................. programmes tracks and reviews
the programme.
for Tuner ............. programmes tuner stations
manually or automatically.
5 DISPLAY/BAND
for CD ................. displays the current track
number and total remaining time
(or current album and track
numbers for MP3 disc) during
playback.
for Tuner ............. selects waveband.
6 Mode Selection
STOP 9 ............ stops CD playback or erases a
CD programme.
PLAY/PAUSE 2;
................................. starts or interrupts CD playback.
ALBUM/PRESET 4 3
for radio .............. selects a preset radio station.
for MP3 disc ..... selects an album.
TUNING 4 ¢
for Tuner ............. tunes to radio stations.
for CD ................. skips to the beginning of the
current/previous/subsequent
track.
................................. fast searches back and forward
within a track/CD.
for clock/timer adjusts the hours and minutes
for the clock/timer function
7 INTERACTIVE SOUND controls:
DBB .................... (Dynamic Bass Boost) enhances
the bass.
DSC..................... (Digital Sound Control) selects
sound characteristics: JAZZ/POP/
CLASSIC/ROCK.
INCREDIBLE SURROUND (IS) .......................
creates a super-enhanced stereo
effect.
8 SOURCE
– selects the respective sound source for CD/
TUNER/TAPE.
– switches on the system.
9 VOLUME (VOL -/+ )
– adjusts the volume level.
0 Ta pe Deck Operation
RECORD● ... starts recording.
PLAY 2 ............ starts playback.
SEARCHà / á fast rewinds/winds the tape.
STOP•OPENÇ0
................................. stops the tape; opens the tape
compartment.
PAUSEÅ ....... interrupts recording or playback.
! OPEN•CLOSE3
– opens/closes the CD door.
Controls available on the remote
control only
@ CD/TUNER/TAPE
– selects the respective sound source.
# MUTE
– interrupts and resumes sound reproduction.
$ SHUFFLE
– plays CD/MP3 tracks in random order.
% SLEEP
– activates/deactivates or selects the sleeper time.
^ TIMER
– activates/deactivates or sets the timer function.
& REPEAT
– repeats a track/disc /all programmed tracks.
