AMPLIFIER SECTION
Output power
- Stereo mode (DIN) ....................................................................................2 x 50 W
- Surround mode (1 kHz) ..................................................... 50 W RMS/channel
Total Harmonic Distortion ............................... 10% at rated power (1 kHz)
Frequency Response .................................................. 180 Hz – 14 kHz / ±1 dB
Signal-to-Noise Ratio ...................................................................... > 65 dB (CCIR)
Input Sensitivity..................................................................................................... 400 mV
TUNER SECTION
Tuning Range .......................................... FM 87.5 – 108 MHz (50 kHz steps)
..........................................................................MW 531 – 1602 kHz (9 kHz steps)
26 dB Quieting Sensitivity ......................................................................... FM 20 dB
26 dB Quieting Sensitivity .......................................................... MW 5000 µV/m
Image Rejection Radio ................................................................................. FM 25 dB
................................................................................................................................ MW 28 dB
IF Rejection Ratio ............................................................................................ FM 60 dB
................................................................................................................................ MW 24 dB
Signal-to-Noise Ratio .................................................................................... FM 55 dB
................................................................................................................................ MW 35 dB
AM Suppression Ratio ................................................................................. FM 30 dB
Harmonic Distortion ............................................................................FM Mono 3%
......................................................................................................................... FM Stereo 3%
...................................................................................................................................... MW 5%
Frequency Response ......................................... FM 180 Hz – 10 kHz / ±6 dB
Stereo Separation ......................................................................... FM 26 dB (1 kHz)
Stereo Threshold ......................................................................................... FM 23.5 dB
DVD SECTION
Laser Type ................................................................................................ Semiconductor
Disc Diameter .............................................................................................. 12cm / 8cm
Video Decoding .................................................................................................. MPEG-2
Video DAC ................................................................................................................ 10 Bits
Signal System ............................................................................................... PAL / NTSC
Video Format ..................................................................................................... 4:3 / 16:9
Video S/N........................................................................................... 56 dB (minimum)
Composite Video Output ................................................................ 1.0 Vp-p, 75
Ω
S-Video Output ............................................................................. Y - 1.0 Vp-p, 75 Ω
........................................................................................................... C - 0.286 Vp-p, 75 Ω
Audio DAC................................................................... Direct Digital Amplification
Frequency Response ................................................. 4 Hz – 20 kHz (44.1 kHz)
................................................................................................... 4 Hz – 22 kHz (48 kHz)
................................................................................................... 4 Hz – 44 kHz (96 kHz)
Digital Output .................................................................. SPDIF Coaxial & Optical
MISCELLANEOUS
Power Supply Rating.............................................................. 220 – 240 V / 50 Hz
Power Consumption ........................................................................................... 250 W
Dimensions (w x h x d) ...................................435 mm x 81 mm x 360 mm
Weight ............................................................................................................................ 7.1 kg
IR REMOTE CONTROL
Effective Range................................................................................................. > 8 Meter
Number of Keys .............................................................................................................. 45
Battery (1.5V) ........................................................................................................ AA x 2
SPEAKERS
Front speakers / Rear (surround) speaker
System ........................................................................................................ 2-way shielded
Impedance........................................................................................................................ 8 Ω
Speaker drivers........................................................................ 3” full range, 1” piezo
Dimensions (w x h x d) ..................................... 96 mm x 155 mm x 95 mm
Weight ............................................................................................................. 0.45 kg/each
Centre speaker
System ........................................................................................................ 2-way shielded
Impedance........................................................................................................................ 8 Ω
Speaker drivers............................................................... 2 x 3” full range, 1” piezo
Dimensions (w x h x d) ..................................... 250 mm x 94 mm x 88 mm
Weight ......................................................................................................................... 0.92 kg
SUBWOOFER
Subwoofer (not magnetically shielded design)............................................ 6.5”
Output power ............................................................................... 100 W (4 Ω, DIN)
THD .............................................................................................................. 10% at 55 Hz
Reproduction frequency response.......................................... 30 Hz – 140 Hz
Phase switch............................................................................................................ 0
O
, 180
O
Input sensitivity (Subwoofer In) ..........................................................200 mVrms
AC power.................................................................................... 220 – 240 V / 50 Hz
Power Consumption ............................................... 66 W (at 1/8 Rated Power)
Dimensions (w x h x d) ................................ 200 mm x 310 mm x 370 mm
Weight ............................................................................................................................ 6.8 kg
Specifications subject to change without prior notice
