4.75 cm/s: 35-12 500 Hz.
@ Signal-to-noise ratio, according to DIN 45 500 and NAB,
weighted/curve A, D=3%:
19 cm/s: >62 dB;
9.5 cm/s: > 60 dB;
4.75 cm/s: > 56 dB.
@ Signal-to-noise ratio, DIN, unweighted, D = 3%, for all speeds:
> 48 dB.
@ Wow and flutter, according to DIN 45 500, weighted:
19 cm/s: <0.10%;
9.5 cm/s: <0.15%:;
4.75 cm/s: <0.20%.
@ Maximum deviation from the nominal tape speed, for ail speeds:
+ 1%.
@ Fast winding/rewinding time for LP 18 (540 m): < 180s.
@ Crosstalk (channel separation) at 1 kHz: > 40 dB.
@ Track separation:
at 1 kHz: >60 dB;
at 35-200 Hz: >35 dB.
@ Equalisation:
19 cm/s: 3180 + 50 us;
9.5 cm/s: 3180 + 90 us;
4.75 cm/s: 3180 + 120 us.
@ Bias and erase frequency: 100 kHz + 10%.
@ Mechanical noise: <37 dBA((ISO noise curve 30).
® (3.43 - unbalanced microphone inputs for low-impedance
(50-2000 ) microphones. Input sensitivity 0.3 mV/2 kQ.
- @ @ - Headphone output socket for headphones having an
impedance between 8 and 2000 Q. Maxium output voltage 3 V/
600 2.
@ @ - Remote control socket, start/stop breakcontact between
pins 1 and 5.
® @ - Sound-on-sound socket.
e - Monitor and line-out sockets, adjustable output voltage
1 V/5-10 kQ; load impedance > 50 kQ.
@ @} - Line-in sockets, input sensitivity 50 mV/68 kQ.
@ Dimensions, width x height x depth: 390 x 390 x 210 mm ap-
prox.
@ Weight: 8 kg approx.
Optional accessories
The accessories listed below may be obtained fom your dealer.
Note: Some accessories may not be available in all countries.
Tapes etc.
@ LP 13-15-18, High Output HiFi long-play tape on metal-look
plastic reels, diameters respectively 13 cm (270 mof tape), 15 cm
(360 m of tape) and 18 cm (540 m of tape).
@ DP 13-15-18, High Output HiFi long-play tape on metal-look
plastic reels, diameters respectively 13 cm (360 m of tape), 15 cm
(540 m of tape) and 18 cm (720 m of tape).
@ ER 13-15-18 ML, empty mtal-look plastic reels, diameter, res-
pectively 13, 15 and 18 cm.
@ SK 10, tape splicing kit.
Microphones
@ N 8215, omni-directional electret HiFi microphone with jack
plug and detachable table stand. Sensitivity 2.5 mV/Pa, frequency
* range 50-18 000 Hz ( —6 dB), impedance 800 Q.
@ N 8310/02, omni-directional electret HiFi microphone with jack
plug and detachable table stand, fitted with wind shield and
‘ adapter for floor stand with 3/8” Whitworth thread, all packed ina
storage cassette. Sensitivity 3mV/Pa, frequency rage 20-
20 000 Hz {—6 dB), impedance 800 ©.
@ N 8501/02, uni-directional (cardioid) electret HiFi microphone
with jack plug and detachable table stand, fitted with wind shield
and adapter for floor stand with 3/8” Whitworth thread, all packed
in a storage cassette. Sensitivity 3.5 mV/Pa, frequency range
50-18 000 Hz ( —- 6dB), impedance 1200 Q.
@ N 8404/02, HiFi stereo microphone pair, comprising two omni-
directional electret HiFi microphones, each with jack plug, with
two table stands packed in a storage box. Sensitivity 2,5 mV/Pa,
frequency range 50-18 000 Hz, (— 6dB), impedance 800 2 (all per
channel).
@ N 8410, deluxe HiFi stereo microphone pair, comprising two
uni-directional (cardioid) electret HiFi microphones, each with
jack plug, windshield and adjustable microphone clamp, with
several accessories for table and floor stand mounting (3/8”
Whitworth threaa), all packed in a deluxe storage case. Sensitivity
3.5 mV/Pa, frequency range 50-18 000 Hz(—6 dB), impedance
1200 Q (all per channel).
Headphones
@ N 6330/02, HiFi stereo headphones with stereo jack plug,
equipped with 12 auxiliary diaphragms for extreme spatial effect.
Frequency range 16-20 000 Hz, impedance 2600 Q, weight
400 g.
@ N 6321, HiFi stereo electret headphones with stereo jack piug.
Frequency range 20-22 000 Hz, weight approx. 350 g.
@ N 6326, HiFi stereo electrt headphones with stereo jack plug.
Frequency range 20-2 000 Hz, weight approx. 350 g.
Additional accessories
@ AH 080, timer.
e@ N 6605, transparent dust protection cover.
@ LFD 3414, remote control unit for starting and stopping the tape
during recording and playback.
Connection, extension and adapter leads
For microphones
@ 4822 321 20364, mono extension lead, fength 500 cm. With
mono jack socket connector and mono jack plug.
@ 4822 321 20367, adapter lead, length 15 cm, for connecting
microphones with 3-pole 180° mono DIN plug. With 5-pole mono
DIN socket connector and mono jack plug.
@ 4822 321 20368, adapter lead,length 15cm, for connecting
stereo microphones with 5-pole 180° stereo DIN plug. With one
5-pole stereo DIN socket connector and two mono jack plugs.
For headphones
@ 4822 321 20316, stereo extension lead, length 500 cm. With
stereo jack socket conector and stereo jack plug.
@ 4822 321 20291, adapter lead, length 15cm, for connecting
headphones with stereo DIN die-5 plug. With stereo DIN die-5
socket connector and stereo jack plug.
With coaxial phono plug.
Connecting leads with four coaxial phono plugs at both ends:
4822 321 20381, length 50 cm;
4822 321 20382, length 250 cm.
@ 4822 321 20383, extension lead, length 250 cm. Withfur coaxial
phono socket connectors and four coaxial phono plugs.
@ 4822 321 20308, connecting lead, length 250 cm. With two
coaxial phono plus at both ends.
@ 4822 321 20307, extension lead, length 250 cm. With two coaxial
phono socket connectors and two coaxial phono plugs.
With coaxial phono and 5-ole 180° DIN plugs
@ Connecting leads with four coaxial phono plugs and one 5-pole
180° stereo DIN plug.:
4822 32 20189, length 120 cm;
4822 321 20198, length 120 cm, with attenuating resistors (1 MQ)
on pins 1 and 4.
Plugs for remote control (pins 1 and 5)
@ 4822 264 40024, 5-pole 240° DIN plug.
@ 4822 264 40027, 5-pole 240° DIN angled plug.
