Philips OptiVision LED - Mounting Procedures; Second Fixing Security for Heights >3 m

3
443000016382_A
07/2015
Data subject to change
Printed in Spain
www.philips.com/lighting
- M16 with extra large washer (not provided)
- M12 with extra large washer (not provided)
1
2
3
4
±40 mm
mm
17
(x2)
50 Nm
17 Nm
(x1)
50 Nm
2x
(x2)
50 Nm
Higher >3m
Use 2
nd
fixing security
