Checking the Voltage Setting
PageWriter 100 M1772A Cardiograph A-3
A
)LJXUH$5HDU9LHZRI&DUGLRJUDSK
A. Equipotential Connector
B. AC Power Receptacle
C. Voltage Select Switch
127( The equipotential connector is only used when the cardiograph must be
plugged into an ungrounded outlet. See "Patient and Operational Safety
Notes" in Chapter 1, Getting Acquainted for more information about
using the equipotential connector.
