Dimensions 240 x 178.5 x 32 mm
Weight 1.0 kg
Power supply Input: 100-240V 50/60Hz 0.5A
Output: DC 9V 1.5A
Power consumption 13. 5 W
Operating temperature range 0-45°C
Laser wavelength DVD: 655 nm
CD: 785 nm
Video output
Format PAL & NTSC
Output level 1Vp - p ± 20%
Load impedance
75
Audio line out
Frequency response 20Hz-20KHz ± 1dB
Signal/noise ratio
80 dB
Audio distortion + noise
-80 dB (1Khz)
Channel separation
80 dB
Dynamic range
80 dB
Audio out (analog audio) Output level: 2V ± 10%
Load impedance
10 k
7 Troubleshooting
Warning
Risk of electric shock. Never remove the casing of the player. •
To keep the warranty valid, never try to repair the system yourself.
If you encounter problems when using the player, check the following points
before requesting service. If the problem remains unsolved, register your
player and get support at www.philips.com/welcome.
