155
Apply
a
3 V
square-wave
voltage,
frequency
2
kHz,
to
the
channel
B input
-
Check
that
the
trace
height
is
6 DIV;
if
necessary,
readjust
GAIN
potentiometer
R13
on
the
front
panel
Check
that
the
control
range
of
the
channel
B
AMPL
vernier
control
is
1:2,6
to
1:3,5
and
the pilot
lamp
UNCAL
lights
up
as soon
as
the
vernier
is
out of
the
CAL
position
—
Remove
the
input
signal
3.4.9.4.
Gain
(sensitivity)
at externai
X deflection
(unit
16)
—
Depress
push-button
EXT
X DEFL
of
the
X
deflection
controls
(S2)
—
Depress
push-button
EXT
of
the
m.t.b.
trigger-source
controls
(S22)
-
Set
the X
AMPL-HOLD
OFF
control
to CAL
-
Apply
a
300
mV
square-wave
voltage,
frequency
2
kHz,
to
the
m.t.b. EXT
input
—
Check
that
the trace
width
is
6
DIV;
if
necessary,
readjust
potentiometer
R742
on the
trigger-source
board
-
Check
that
the
control
range
of the
X AMPL-HOLD
OFF
control
is 1
:2,6
to 1
:3,5
—
Set the X
AMPL-HOLD
OFF
control
to
CAL
—
Depress
push-button EXT
-r
10
(S22) of
the
m.t.b. trigger-source
controls
—
Increase
the amplitude
of the
input
signal by a factor of 1
0
—
Check
that the
trace width
is
6 DIV
±
2 SUBDIV
—
Remove
the input
signal
3.4.9.5. Gain (sensitivity)
external triggering
via
TRIG VIEW (unit
9)
—
Depress
push-button TRIG VIEW
of the
display mode controls (SI
)
—
Depress
push-button MAIN
TB of the
X deflection controls (S2)
—
Depress
push-button EXT
of the
m.t.b. trigger-source controls (S22)
—
Apply
a 600 mV
square-wave voltage,
frequency 2 kHz, to the m.t.b. EXT input
—
Check
that the trace height
is 6 DIV; if necessary, readjust potentiometer R852
on
the trigger-amplifier
board
—
Remove
the input signal.
3.4.9.6. Gain (sensitivity)
TRIG VIEW
—
Depress push-button TRIG VIEW
of the display-mode controls
(SI)
—
Set the channel A AMPL
switch to .5 V/DIV and its vernier to CAL
—
Depress
push-button A (S22) of the m.t.b. trigger-source controls
—
Apply
a 3
V
square-wave voltage, frequency
2
kHz,
to the
channel
A input
—
Centre the display, using
the m.t.b.
LEVEL
control
R7
—
Check that the trace height
is
6
DIV ±
3
SUBDIV
3.4.9.
7.
Gain (sensitivity) Yg
TRIG VIEW
—
Depress push-button TRIG VIEW
of the display-mode controls (SI).
—
Set the channel B AMPL
switch
to
0.5 V/DIV and its vernier
to
CAL
—
Depress
push-button B (S22) of the m.t.b. trigger-source controls.
—
Apply
a 3 V square-wave voltage, frequency 2 kHz, to the channel B input.
—
Centre the display,
using the m.t.b. LEVEL control R7.
—
Check
that the trace height is 6 DIV
±
3 SUBDIV
3.4.9.8. Gain (sensitivity) Yg VIA X
—
Depress push-button A of the display -mode controls (SI
)
—
Depress push-button
EXT
X DEFL of the X deflection
controls
(S2)
—
Push
the
Y
POSITION
controls to position NORMAL
—
Depress push-button AC of the channel B signal-coupling controls
—
Depress
push-button
B
S22 of the m.t.b. trigger-source
controls
—
Set the
d.t.b.
TIM E/D IV
switch
to
OFF
—
Set the channel B
AMPL
switch
to .5
V/DIV
and its vernier to
CAL
—
Apply
a 3
V
square-wave voltage, frequency 2
kHz,
to
the channel B input
—
Check that the trace width is
6
DIV
±
1
SUBDIV
—
Remove
the input signal.
3.4.10.
Vertical channels
The adjustments of the vertical channels A
and
B are identical.
The knobs,
sockets and adjusting
elements
of channel B are shown in brackets after those of channel A.
Before
performing the following tests,
the
balances
and sensitivities must be
checked
in
accordance with sections 3.4.7. and 3.4.9.
