25
2.2.4.
2.2.4.1.
2.2.4.2.
2.2.4.3.
2.2.5.
2 . 2 . 6 .
2.2.7.
2 . 2 . 8 .
*
2.2.9.
Mains supply conditions in accordance with IEC 359, Group S2
Mains supply voltage
Reference value 220 V, ± 1 %
Rated range of use 220 V, ± 10 %
Note: .
Instrument can be altered for nominal mains voltage of 110 V and 240 V
Mains supply frequency
Reference value
Rated range of use
50 Hz/60 Hz
47 Hz ... 63 Hz
Power consumption
Power consumption 10 VA
Input terminals arrangement
Number of input terminals Three x 4 mm terminals; 0, V-12 - mA and 0,2 A - 10 A
One 8 pole DIN socket; PROBE
Asymmetrical, floating
Time function ADC
Conversion rate
Range changing time
Recovery time after overload
Calibration
Recalibration interval
Mechanical
Dimensions
Weight
Cabinet material
2,5 conversions /s
62 ms
Range 200 mV : max. 7 s
Range 2 V 2000 V : max. 1 s
1 year
Height 95 mm
Width
235 mm
Depth
280 mm
2 kg
ABS
Safety
Class II in accordance with IEC 348
V
