Sound Performance:
At 360 mv RMS/1 kHz to Audio input;
Output 1 Watt per channel or 3 Watts per channel with <10% Total Harmonic Distortion (THD).
At 1 Watt RMS, both channels driven, response is within ± 2dB from 20Hz to 20kHz.
Power Supply Voltages:
NAME VALUE TOLERANCE AT COMPONENT
V+3.3 3.3 volts +/- 0.3 volt 2604
V+5vD 5 volts +/- 0.8 volt Emitter of 7612
V+5v 5 volts +/- 0.5 volt Pin 6 of 1000
Vstby 5 volts +/- 0.5 volt 3615
V+7.5v 7.5 volts +/- 0.5 volt 2414
V+8.5v 8.7 volts +/- 0.8 volt 2415
VmainAux 9 volts +/- 1 volt 2561
Vsound 10.5 volts +/- 1 volt 2955 (2X1 W stereo, 1 W mono)
Vsound 16.5 volts +/- 1 volt 2955 (2X3 W stereo)
V+13v 13.5 volts +/- 1 volt 2410 (13“ and 19“ models)
V+13v 13.8 volts +/- 1 volt 2410 (20“ models)
V-13v -13.5 volts +/- 1 volt 2410 (13“ and 19“ models)
V-13v -13.8 volts +/- 1 volt 2410 (20“ models)
MainSupply 95 volts +/- 1.5 volts Pin 2 of 5445
V+190v 190 volts +/- 10 volts 2413
190V 190 volts +/- 10 volts Pin 3 of connector 0244
Mains (AC Power):
60 Hz, 120 volts AC nominal:
Allowed 90 to 132 volts AC
For Auto-Multi-Voltage Only:
60 Hz, 90 to 276 volts AC
Power consumption, worst control setting:
13“ models – 48 Watts
19“ models – 63 Watts
20“ models – 70 Watts
Standby power consumption:
3 Watts +/-10%
High Voltage (EHT):
(At minimum brightness)
Screen Size: 13" 19" 20“
Voltage: 24.1kV +/- 1kV 25.4kV +/- 1kV 27.2kV +/- 1.5kV (for reference only)
Color Temperature:
NORMAL WARM COOL
9200 +/- 10% 8200 +/- 15% 10,200 +/- 15%
Note: Nominal specifications represent the design specifications. All units should be able to approximate
these. Some will exceed and some may drop slightly below these specifications. Limit specifications
represent the absolute worst condition that still might be considered acceptable. In no case should a unit fail
to meet limit specifications.
