Philips Satinelle Advanced User Manual

Problem Solution
During use,
the appliance
becomes hot and
suddenly stops
operating. Then
the speed lights
and the battery
indicator ash red
for 30 seconds.
The overheat protection has been activated. The
overheat protection switches o the appliance
automatically if it becomes too hot. To reset the
overheat protection, let the appliance cool down
and then switch it on again. To avoid overheating
of the appliance, do not press it too hard onto
you skin.
My skin is irritated
after I have used
the appliance.
Slight skin irritation like red skin or red dots may
occur. This is normal. To avoid irritated skin, make
sure that you gently move the appliance against
the direction of hair growth. Do not apply too
much pressure. If the irritation lasts longer than
3 days, we advise you to consult a doctor.
Always stretch the skin with your free hand. When
you use the appliance on your underarms, raise
your arm and put your hand on the back of your
head to stretch the skin (Fig. 14).
한국의
소개
필립스 제품을 구입해 주셔서 감사합니다! 필립스가 드리는 지원 혜택을
최대한 누리시려면 www.philips.com/welcome에서 제품을 등록하십시오.
구성품 명칭(그림 1)
1 핸들
2 속도 표시등(I과 II)
3 전원 버튼
4 배터리 표시등
5 열림 버튼
6 소형 플러그 콘센트
7 제모 헤드
8 내장 전구
9 마사지 캡
10 얼굴 캡
11 민감 부위용 캡
12 피부 스트레처 캡
13 쉐이빙 헤드
14 포일
15 트리머
16 쉐이빙 헤드용 빗
17 트리머 헤드
18 트리머 헤드용 빗
19 결합부
20 바디 마사지 헤드
21 바디 각질 제거용 브러시
22 바디 각질 제거용 브러시 보호 캡
23 청소용 브러시
24 어댑터(HQ8505; 입력: 100-240Vac; 50/60Hz; 9W, 출력:
15Vdc; 5.4W)
25 조명달린 족집게
그림 표시 안 됨: 파우치
참고: 제공되는 헤드 및 액세서리는 모델 번호에 따라 다릅니다. 특정
제품과 함께 제공되는 헤드 및 액세서리는 개요 그림을 참조하십시오.
충전
참고: 제품을 처음 사용하기 전에 완전히 충전하십시오.
참고: 이 제품은 무선으로만 작동됩니다.
제품을 충전하려면 소형 플러그를 제품 밑면의 소켓에 꽂고 어댑터를 벽면
콘센트에 연결하십시오.
- 충전 표시등이 흰색 (그림 2)으로 깜박이면 제품이 충전 중입니다.
충전 시간은 최대 1.5시간 걸립니다.
- 배터리 충전 표시등이 계속 흰색 (그림 3)으로 켜져 있으면 제품이
완전히 충전된 것이며 최대 40분간 무선으로 사용할 수 있습니다.
- 제품이 켜져 있을 때 충전 표시등에 불이 들어오지 않으면 제품이
완전히 충전된 것입니다.
- 배터리 표시등이 주황색 (그림 2)으로 깜박이면 배터리가 거의 방전된
것이며 충전해야 합니다. 사용이 끝나면 제품을 충전하십시오.
참고: 완전히 충전된 제품을 전원에 그대로 연결한 상태에서 전원 버튼을
누르면 배터리 표시등이 몇 차례 깜박입니다. 이것은 제품을 켜려면 전원
콘센트에서 분리해야 한다는 뜻입니다.
Place the trimming head at onto the skin to trim (Fig. 16). Place the
trimming head perpendicularly onto the skin for styling and shaping
(Fig. 17).
Comb for trimming head
You can attach the comb onto the trimming head to trim hairs in the
bikini area to a length of 3mm (Fig. 18).
Body massage head
The body massage head rotates rmly to relax your muscles.
Note: You have to put the body massage head on the coupling unit
before you can attach it onto the handle (Fig. 19).
Body exfoliation brush
You can use the body exfoliation brush to remove dead skin cells.
Do not use the body exfoliation brush on your face.
Note: You have to put the body exfoliation brush on the coupling unit
before you can attach it onto the handle (Fig. 20).
Cleaning and storage
Keep the adapter dry.
1 To clean the epilating head, hold the appliance upside down,
switch it on and rinse it with cold water for 15 seconds after every
use (Fig. 21).
2 To clean the shaving head (if supplied): Use the cleaning brush to
brush away any hairs that have collected under the trimmers. Grab
the two trimmers of the cutting unit and pull the cutting unit out of
the shaving head (Fig. 22). Clean all parts of the shaving head with
the cleaning brush, except the foil.
Note: Lubricate trimmer teeth and foils with a drop of sewing
machine oil every six weeks for optimal performance.
3 Rinse the cutting unit, heads and accessories under the tap. Shake
them rmly to remove water drops.
4 Let all parts dry completely.
5 Place the cutting unit back into the shaving head (‚click‘).
6 Put protection caps or combs on the heads to prevent damage to
the heads when you store them.
7 Store the appliance, its heads and accessories in the pouch.
Note: Lubricate trimmer teeth and foils with a drop of sewing machine
oil every six weeks for optimal performance.
Replacement
To buy accessories or spare parts, visit www.shop.philips.com/service
or go to your Philips dealer. You can also contact the Philips Consumer
Care Centre in your country (see the worldwide guarantee leaet for
contact details).
Shaving head (if supplied): For optimal performance, we advise you
to replace the cutting unit of the shaving head every two years. If you
use the shaving head twice or more times a week, replace the cutting
unit more often. Always replace the cutting unit with one of the original
type (BRL384).
Body exfoliation brush (if supplied): If you use the body exfoliation brush
2-3 times a week, it lasts approximately 3 months. Replace the body
exfoliation brush every 3 months with one of the original type (BRE351).
Troubleshooting
This chapter summarises the most common problems you could encounter
with the appliance. If you are unable to solve the problem with the
information below, visit www.philips.com/support for a list of frequently
asked questions or contact the Consumer Care Centre in your country.
Problem Solution
The appliance
does not work as
well as it should.
Make sure you hold the appliance at the correct
angle (Fig. 12) and move it across the skin slowly,
against the direction of hair growth.
Clean the heads and accessories after every use.
After charging, the
battery indicator
ashes when I
press the on/o
button, but the
appliance does
not switch on.
The appliance is still connected to the mains. In
this case, the battery indicator ashes to indicate
that you should disconnect the appliance from
the mains before you can switch it on.

Philips Satinelle Advanced Specifications

General

Brand	Philips
Model	Satinelle Advanced
Category	Epilator
Language	English
