2 - 4 Quick Start Guide - IR Dongle v2.0 December 2018
Visual Feedback
LED blinks 3 times:
OK to proceed
LED blinks 6 times:
“Invert Signal” in Preferences of Philips Field Apps.
Selection Switch
2 LEDs are available for use depending upon the application:
• An LED (on top side) for long distance communication; ideal for
highbay/industry application (up to 16m/50ft)
•
An LED (on side) for short distance communication; ideal for office
applications (up to 8m/25ft)
IR Dongle v2.0
Signal LED
(red in color)
Long
Distance
(highbay)
Short Distance
(office)
Short Distance (office)
OFF
Long Distance (highbay)
