Still/Slow Control
Frame Advance Timing Chart
1) SP Mode
Fig. 3
1
8 RF-SW
F
-AD
(
Internal Signal)
C-DRIVE
P
B CTL
7
8 C-F/R
1
6 H-A-SW
1
5 ROTA
AT
"H"
"Z"
"H"
"L" "L"
ST
BL
STILL FRAME ADVANCE STILL
The first rise of RF-SW after a rise in F-AD signal
Stop detection (T2)
Slow Tracking Value
Acceleration Detection (T1)
Reversal Limit Value
20ms
