Philips VR140/02 - Mechanical Parts List

MECHANICAL PARTS LIST
Pos. h 12 NC Description
A1X 9965 000 17180 FRONT ASSEMBLY HE270ED
11 1
A1X 9965 000 17212 FRONT ASSEMBLY HE272FD
1
A1X 9965 000 17214 FRONT ASSEMBLY HE490BD
1
A1X 9965 000 17226 FRONT ASSEMBLY HE491ED
11
A1X 9965 000 17227 FRONT ASSEMBLY HE492FD
1
A2 9965 000 16612 CASE, TOP HE470ED
1111
A2 9965 000 17142 CASE, TOP(U27 FTZ 435) HE480ED
1111
A3 9965 000 16613 CHASSIS HE470ED
1111
A3 9965 000 17143 CHASSIS(U27 FTZ 435MM) HE480ED
1111
A7 9965 000 16614 PANEL, BOTTOM HE470ED
1111
A7 9965 000 17144 PANEL, BOTTOM(435MM) HE480ED
1111
A29 9965 000 17140 CHASSIS FOOT H79P9JD
11111111
1B1 DECK ASSEMBLY CZD012/VM1720
11 1
1B1 DECK ASSEMBLY CZD012/VM1721
1
1B1 DECK ASSEMBLY CZD012/VM17E0
1111
2B5 9965 000 12168 SHEILD, CYLINDER HC460ED
11111111
2L011 9965 000 16615 SCREW, P-TIGHT 3X10 BIND HEAD+
11111111
2L012 9965 000 16615 SCREW, P-TIGHT 3X10 BIND HEAD+
11111111
2L021 4822 502 30752 SCREW, P-TIGHT M3X10 WASHER HEAD+
11111111
2L031 4822 502 14009 SCREW, S-TIGHT M3X6 BIND HEAD+
11111111
2L041 4822 502 14012 P-TIGHT SCREW 3X8 BIND +
11111111
2L042 4822 502 14012 P-TIGHT SCREW 3X8 BIND +
11111111
2L043 4822 502 14012 P-TIGHT SCREW 3X8 BIND +
1111
2L044 4822 502 14012 P-TIGHT SCREW 3X8 BIND +
1111
2L051 4822 502 14018 SCREW, S-TIGHT M3X5 BIND HEAD+
11111111
2L099 9965 000 13027 SCREW, P-TIGHT M3X8 BIND HEAD+
11111111
PACKING
X1 9965 000 17184 REMOTE CONTROL UNIT 364/CRC007
1111
X1 9965 000 17215 REMOTE CONTROL UNIT 364/CRC007
1111
X3 9965 000 17134 RF CABLE CC1001020012010
11111111
X3 4822 320 50377 RF CORD PAL 1.2M
11111111
X4 ACCESSORY BAG K8092BA
11111111
X6 9965 000 17135 21P SCART CABLE SD-0799(SG-D91050)
11
PRODUCT SAFETY NOTE: Products marked with a
h
have special characteristics important to safety.
Before replacing any of these components, read carefully
the product safety notice in this service manual.
Don’t degrade the safety of the product through improper servicing.
VR140/02 VR840/39 VR840/58 VR140/39 VR840/07 VR140/07 VR140/58 VR840/16
1-18-2
