Philips VR140/02 - Page 63

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR140/39 VR140/02 VR140/07 VR840/58 VR140/58 VR840/07 VR840/16 VR840/39
CAPACITORS
C1 CHIP CERAMIC CAP. F Z 0.1UF/25V
1111
C4 CHIP CERAMIC CAP. CG J 56PF/50V
1111
C5 CHIP CERAMIC CAP. CG J 22PF/50V
1111
C6 CHIP CERAMIC CAP. CG J 56PF/50V
1111
C7 CHIP CERAMIC CAP. CH C 3PF/50V
1111
C8 CHIP CERAMIC CAP. CH C 3PF/50V
1111
C11 CHIP CERAMIC CAP. B K 0.01UF/50V
1111
C12 ELECTROLYTIC CAP. 10UF/16V M H7
1111
C13 CHIP CERAMIC CAP. B K 0.01UF/50V
1111
C14 CHIP CERAMIC CAP. B K 0.01UF/50V
1111
C15 ELECTROLYTIC CAP. 10UF/16V M H7
1111
C16 ELECTROLYTIC CAP. 10UF/16V M H7
1111
C17 CHIP CERAMIC CAP. F Z 0.1UF/25V
1111
C19 CHIP CERAMIC CAP. F Z 0.1UF/25V
1111
C20 ELECTROLYTIC CAP. 3.3UF/50V M H7
1111
C21 CHIP CERAMIC CAP. FZ Z 0.1UF/50V
1111
C22 ELECTROLYTIC CAP. 10UF/16V M H7
1111
C23 CHIP CERAMIC CAP. F Z 0.47UF/10V
1
C24 ELECTROLYTIC CAP. 0.22UF/50V M H7
1111
CN1 4822 265 11267 ANGLE PIN HEADER, 9P 6029B-1-09Z003-T
1111
DIODES
D2 4822 130 30621 SWITCHING DIODE 1N4148M
1111
IC’s
IC1 9965 000 14760 IC:AUDIO PROCESSOR MSP3417G-QG-B8-V3
1111
COILS
L1 4822 157 10889 INDUCTOR 10UH-K-26T
1111
L2 PCB JUMPER D0.6-P5.0
1111
L3 4822 157 11318 INDUCTOR 18UH-K-26T
1111
L4 4822 157 10889 INDUCTOR 10UH-K-26T
1111
RESISTORS
R1 CHIP RES.(1608) 1/10W J 1K OHM
1111
R2 CHIP RES.(1608) 1/10W 0 OHM
1
R4 CHIP RES.(1608) 1/10W J 120K OHM
1111
R5 CHIP RES.(1608) 1/10W 0 OHM
1111
R6 CHIP RES.(1608) 1/10W 0 OHM
1111
R7 CHIP RES.(1608) 1/10W J 1.2K OHM
1
X1 9965 000 12200 X’TAL 18.432MHZ
1111
