Dear Customer,
Congratulations on buying your Phocos product! Please read the instructions carefully and
thoroughly before using the product. Your new CXup controller is a “state-of-the-art” device
which was developed in accordance with the latest available technical standards. It comes with
a number of outstanding features, such as:
User friendly LC display shows extensive system information
Four-stage PWM charging algorithm with integrated temperature compensation for lead
battery and two stage charge algorithm for LiFePO4 battery
Full electronic protection
Programmable nightlight function
USB charging port
Integrated two year data logger with data export
Load status indication
Touch buttons ensure long lasting operation
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions for CXup controller that shall be followed during
installation, operation and maintenance of the charge controller.
RISK OF FIRE: ATTACH THE TEMPERATURE SENSOR TO THE BATTERY.
Battery type: Lead acid (GEL, AGM, flooded), LiFePO4
Nominal voltage rating of the battery: 12 or 24 V
Battery fuse: Use a fast acting fuse with an interruption rating capacity of 1000 A on the battery
side. We recommend to use a fast acting melting fuse (e. g. car type fuses) as close as possible
to the battery terminal. The maximum current rating should be 1.5 times of the nominal current
of the charge controller. Respect the maximum current rating of the BMS when using LiFePO4
batteries.
Please do not disassemble or attempt to repair Phocos products. Phocos charge controllers do
