4 Operator Panel Features
4.1 Power Indication Lamp
The red, sealed, high intensity AC voltage power indication
lamp allows operators to visually identify the operation
status of several Phoenix Centrifugal Air Movers at a
distance, with a single glance. The power indication lamp
will remain lit when the AC power cord is plugged into a
standard “powered” AC power outlet and the
3-Position drying selector switch is in either the HIGH or
LOW operation position. The power indication lamp will
remain unlit when the AC power cord is unplugged, the
3-Position drying selector switch in the OFF position, or the
connected, standard AC wall outlet power has been turned
off.
4.2 3-Position Drying Selector Switch
The Phoenix Centrifugal Air Mover features a three-position
switch - LOW–OFF–HIGH.
1. Inspect the machine for damage and airflow
obstructions prior to plugging it in or operating it.
2. Ensure the power switch is in the OFF (middle)
position.
3. Place the machine into the desired position for
operation. Ensure that the machine rests stable and
secure and will not overturn.
4. Turn the unit on to the desired speed, high or low.
5 Maintenance
WARNING: Disconnect the unit from power before servicing
or cleaning. Replace the safety grill after
servicing, lubrication or cleaning.
5.1 Servicing
Before each use, inspect for damage, blocked inlet or
outlet, or any excess buildup of foreign material.
When the Phoenix Centrifugal Air Mover is first turned
on, check for excessive vibration. If the unit vibrates
excessively or if blower wheel rubs on housing, turn off the
unit immediately. Have a service technician inspect the
unit to locate the problem.
5.2 Cleaning
The housing is made of a durable and washable
polyethylene. When cleaning, the use of solvents is NOT
recommended.
6 Replacement Parts and
Optional Accessories
Contact the factory at 1-800-533-7533 to order
replacement parts, or optional accessories
