Phoenix RSM-10P - Display

4.2 Display
Temperature display area
Speed display area
Figure 6 Digital hotplate model
Characters
Descriptions
Temperature
display area
When heating function was switched ON,
LED displays the temperature setting
value and shifts to real value in 5 seconds.
When the heating function is switched
OFF and the hotplate temperature is still
above 50°C, LED displays “Hot”,
otherwise LED displays OFF.
Speed display
area
When stirring function was switched ON,
LED displays the speed setting value and
flashes. The setting value does not flash
until real speed reaches the set point.
Table 3
Speed display area
Figure 7 Digital model
Characters
Descriptions
Speed display
area
When stirring function was switched
ON, LED displays the speed setting
value and flashes. The setting value
does not flash until real speed reaches
the set point.
Table 4
