PHOENIX METAL PRODUCTS, INC
TL600/TL700 LAVATORY SERVICE TRUCK
25
MAY 2018
CHAPTER 1
SECTION 3 - OPERATION
LAVATORY SERVICE EQUIPMENT
(1) CHECK LEVEL OF FLUSH TANK LEVEL GAUGE.
CAPACITY OF TANK IS 240(TL600) OR 300(TL700) U.S. GALLONS. (FIGURE # 4.)
(2) ASSURE THAT THE WASTE TANK IS EMPTY OR THAT THERE IS SUFFICIENT
CAPACITY REMAINING FOR THE INTENDED USE.
CAPACITY FOR WASTE TANK IS 360(TL600) OR 400(TL700) U.S. GALLONS.
(FIGURE # 4)
(3) CHECK CONDITION OF BOTH HOSES, WASTE HOSE AND FILL HOSE.
CHECK FOR CUTS, HOLES OR TWISTING OF HOSE. CHECK CONDITION
OF BOTH AIRCRAFT COUPLINGS. (FIGURE # 5)
(4) CHECK LEVEL OF HYDRAULIC TANK. OPEN HYDRAULIC TANK
COMPARTMENT LOCATED ON PASSENGER SIDE OF MODULE. THE SIGHT
GAUGE SHOULD READ FULL. IF LEVEL IS BELOW FULL FLUID MUST BE
ADDED. (FIGURE # 6)
(5) IF UNIT IS BEING USED IN SUB-FREEZING WEATHER, BE SURE TO DISCONNECT
THE 110 VOLT AC CABLE FROM THE OUTLET ON DRIVERS SIDE. (FIGURE # 6)
(6) CHECK CONDITION OF WASTE TANK DRAIN VALVE. CHECK CONDITION OF
WASTE TANK DRAIN VALVE HANDLES. (FIGURE # 5)
IF ALL FUNCTIONS AND INSPECTIONS CHECK OUT, THE VEHICLE AND
SERVICING MODULE ARE READY FOR OPERATION.
BE SURE DRAIN VALVE IS CLOSED!
