PHOENIX METAL PRODUCTS, INC
TL600/TL700 LAVATORY SERVICE TRUCK
9
MAY 2018
(1) DESCRIPTION: ISUZU, CAB OVER—MODEL NPR W4500— GVWR 14,500 LBS
WHEELBASE 132.5”
(2) CHASSIS SPECIFICATIONS:
GASOLINE:
A. ENGINE - GMPT L96 VORTEC V - 8, 365 in
3
(6.0L). 300 HP@4400 RPM 360 FT LBS TORQUE
@ 4000 RPM.
B. TRANSMISSION - 6L90-E HYDRA-MATIC 6 SPEED AUTOMATIC W/ LOCK UP
TORQUE CONVERTER AND OVERDRIVE.
C. FRONT AXLE - REVERSE ELLIOT “I” BEAM - SEMI ELLIPTICAL STEEL LEAF
SPRINGS AND SHOCK ABSORBERS. GAWR– 5,360 LBS
D. REAR AXLE - FULL FLOATING SINGLE SPEED WITH HYPOID GEARING RATED AT
11,020 LBS. GAWR - 9,880 LBS
E. BRAKES - DUAL CIRCUIT VACUUM ASSISTED HYDRAULIC BRAKES WITH LOAD SENSING
PROPORTIONING VALVE. DISC FRONT AND SELF ADJUSTING CABLE ACTUATED DRUM
TYPE MOUNTED ON TRANSMISSION. ANTI- LOCK BRAKING SYSTEM.
F. TIRES/WHEELS - 215/85R-16E - REAR AND 225/75 R-16E FRONT. 10 PLY TUBELESS STEEL
BELTED RADIALS - ALL SEASON. 16 X 6 - 6 HOLE DISC WHEELS
G. FUEL TANK - CAPACITY 30 U.S. GALLONS, AFT MOUNTED
CHAPTER 1
GENERAL INFORMATION AND OPERATION INSTRUCTIONS
SECTION 1 - SPECIFICATIONS AND CAPABILITIES
Property of American Airlines
