Ref. Phonic Part No. Specications
MISCELLANEOUS ITEMS
BOM
R1.2 003-13078-602-0 CEMENT RES. 13 J 30W
R4 003-2008B-601-0 CEMENT RES. 2ohm 25W J AL
R3 003-2508B-601-0 CEMENT RES. 2.5ohm 25W J AL
C4 051-10534-050-0 M.P/C 1UF 250V J MKP -25__85
C3 051-10634-150-0 M.P/C 10UF 250V J MKP -25__85
C5 051-30534-050-0 M.P/C 3UF 250V J MKP -25__85
C1 051-40634-050-0 M.P/C 40UF 250V J SPIRIT -25__85
C2 051-47634-050-0 M.P/C 47UF 250V J SPIRIT -25__85
L3 075-12011-000-0 INDUCTANCE 1.2mH J L=1.0mm
L2 075-28011-000-0 INDUCTANCE 2.8mH J L=1.2mm
L1 075-35011-000-0 INDUCTANCE 3.5mH J L=1.2mm
L4 075-50001-000-0 INDUCTANCE 0.5mH J L=1.0mm
211-01602-000-0 JACK D6.3mm BJ12-2 1/4”
211-03400-021-0 SPEAKON/J SVP563S-CH
211-13000-700-0 LAMP JACK D17*10t PH=5mm
262-24000-700-0 LAMP 24V/75W
290-70026-001-0 ES153 PCB 233*190*1.6
290-70215-000-0 ES153 108*87*1.6
321-00000-020-0 CABLE TIE 140MM
WOOFER 380-60200-000-0 WIRE.UL1015#16 L=550 2*205#PIN RED/BLK
MID SPK. 380-60250-000-0 WIRE.UL1015#16 L=800 2*205# PIN BRO/GRE
TWEETER 380-60260-000-0 WIRE.UL1015#16 L=700 2*205# PIN YEL/BLU
380-60270-000-0 WIRE.UL1015#14 L=600 ORANGE
380-60280-000-0 WIRE.UL1015#14 L=600 WHT
552-60032-500-0 140*160*2t ES153
552-60029-500-F TERMAINAL PANEL ES153
JACK*4 590-03012-200-0 M/E FLT SCR. M3.0*12 BLK D=5.6mm
BOSS*4 590-53008-200-0 M/E SET SCR. M3.0*8 D=6 BLK
592-54020-200-0 W/O SET D4*20 BLK
600-00302-210-0 HEX. NUT M3.0*2.2 NI
600-00822-000-0 HEX.NUT M9*12*2 NI
615-70006-630-0 BOSS M3*5*27.5
633-70001-000-0 RUBBER 25*25*5t BLK
