Phonic K16 Service Manual

PHONIC CORPORATION
PANEL LAYOUT
K16 SERVICE MANUAL
Page 4Page 3
CH13-16 / MAIN / OSP EFI 027-10326-020-0 DSP EFFECT 541-60005-820-0
CH1-12 / AUX 1,2 026-10326-040-0 AUX S / KNOB 541-60005-920-0 MONO 541-60005-220-0 ALL CH1-12 541-60005-020-0
P / KONB 542-20300-211-0 P / KNOB 542-60090-222-0 PFL / ON OFF 210-02201-440-0
PAN 023-10350-020-0 R / KNOB 540-60300-420-0
AUX P / KNOB 540-60300-520-0 EFX1, EFX2, AUX 1, AUX2 022-20350-001-0 R / KNOB EF1,2 54060300-220-0 PAN 023-10350-020-0 R / KNOB 540-60300-420-0
HIGH / LOW / MID 022-50350-050-0 R / KNOB 540-60300-420-0
FREQ 023-10470-021-0 HF / MF / L F 540-60300-420-0
R / KNOB 540-60300-420-0 HF / MI / L F 023-50350-060-0
GAIN 023-50350-011-0 R / KNOB 540-60300-220-0
AUX 1.2 / EFX1,2 /RTN1,2 023-30350-011-0 AUX R /KNOB 540-60300-520-0
EQ 027-10472-000-0 EQ VR 541-20270-020-0
210-01202-120-0
ON / MAIN AUX 210-02402-050-0 P / KNOB 542-20300-221-0
P / KONB 542-20300-211-0 P / KNOB 542-60090-222-0 PFL / ON OFF 210-02201-440-0
LPF 023-50340-023-0 VR 023-50340-023-0
P / KONB 542-20300-211-0 P / KNOB 542-60090-222-0 PFL / ON OFF 210-02201-440-0
PROGRAM 210-16000-000-0 R / KNOB 540-20460-220-0
PARAMETER 022-20350-010-0 R / KNOB] 540-60300-220-0
12V LAMP 211-03300-160-0
SPEAKON 211-03400-021-0
PARALLEL 211-01602-560-0
PARALLEL 211-01602-560-0
P / KNOB 542-60280-020-0 PSH / SW 210-02101-030-0
AC / IN 211-12300-010-0
FOOT SW 211-01602-380-0
PHANTOM POWER 210-07100-00-0
PHANTOM POWER 210-07140-000-0
COM BO 211-03300-030-6
PAD 210-02202-070-0 P / KNOB 542-60090-222-0
INS / AMP INPUT 211-01602-380-0
GAIN 023-10350-020-0 R / KNOB 540-60170-120-0
MIC JACK 211-033000-030-6
VOCAL SW 210-01202-360-0
RCA JACK 211-00041-100-0
MINI JACK 211-01302-140-0
EFX , AUX 211-01602-390-0
JACK 211-01602-610-0
AMP MODE 210-01204-020-0
SPS 210-01202-360-0
TWO CHANNEL POWER AMP 210-01403-010-0
ZONE2 210-01202-360-6
