Phonic PCX 3000 - Dimensions; Specifications; Appendix

PCX3000
English
5
SPECIFICATIONS
Audio Inputs
Connectors XLR
Type Electronically servo-balanced, HF ltered
Input Impedance Balanced >50 kohm, unbalance >25 kohm
Max. Input Level +22 dBu typical, balanced or unbalanced
CMRR >40dB, typical >55dB at 1 kHz
Audio Outputs
Connectors XLR
Type Electronically servo-balanced, HF ltered
Output Impedance Balanced 60 ohm, unbalance 30 ohm
Max. Output Level +20 dBu, balanced or unbalanced
Performance
Bandwidth 20 Hz to 20 kHz, +0/-0.5 dB
Frequency Response <5 Hz to >60 kHz, +0/-3 dB
Signal to Noise Ratio
Ref.: +4 dBu, 20 Hz to 20 kHz, unweighted
Stereo-Mode: Mono-Mode:
Low Output >94 dB >94 dB
Mid Output >96 dB
High Output >92 dB >92dB
Dynamic Range >106 dB, unweighted
THD & Noise <0.04%
Interchannel Crosstalk
High to Low: <93 dB
High to Mid: <95 dB
Mid to Low: <96 dB
Crossover
Filter-Type Linkwitz-Riley, 24 dB/octave, state-variable
Mono Mode Frequencies x1 x10
Low/High 44 to 930 Hz 440 Hz to 9.3 kHz
Low/Mid 44 to 930 Hz 440 Hz to 9.3 kHz
Mid/High 440 Hz to 9.3 kHz
Stereo Mode Frequencies x1 x10
Low/High 44 to 930 Hz 440 Hz to 9.3 kHz
USA/Canada 120V ~, 60 Hz
Europe/U.K./Australia 230V ~, 50 Hz
Japan 100V ~, 50-60 Hz
Power Consumption <20 W
Fuses
100-120 V ~, T630 mA H
200-240V ~, T 315 mA H
Mains Connection Standard IEC receptacle
Dimensions 19” x 1.7” x 8.2” (483 x 44 x 208 mm)
Net Weight 2.13 kg (4.7 lbs)
